Planet GSD-1020S is an 8-Port Gigabit Ethernet Switch with two SFP interfaces specifically designed for building Gigabit backbones capable of reliably sending and receiving data to remote locations via fiber optics.
Besides support for 20Gbps switch fabric to handle extremely large amounts of video, voice and important data in a secure topology, the GSD-1020S switch provides user-friendly but advanced IPv6 / IPv4 management interfaces and abundant L2 / L4 switching functions.
The features of enhanced management are:
| Switch type | Managed |
| Switch layer | L2+ |
| System event log | |
| Quality of Service (QoS) support | |
| Reset button | |
| Web-based management | |
| Traffic classification | |
| ARP inspection |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 2 |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Full duplex | |
| Spanning tree protocol | |
| 10G support | |
| Flow control support | |
| Port mirroring | |
| Link aggregation | |
| Auto MDI/MDI-X |
| Switching capacity | 20 Gbit/s |
| Throughput | 14.8 Mpps |
| MAC address table | 8000 entries |
| Store-and-forward | |
| Number of queues | 8 |
| Jumbo frames support | |
| Jumbo frames | 10000 |
| VLAN support | |
| Number of VLANs | 4094 |
| Private VLAN | |
| Tagged VLAN | |
| Protocol-based VLAN |
| Multicast support |
| Fiber ethernet cabling technology | 1000BASE‑LX,1000BASE‑SX |
| BPDU filtering/protection | |
| MAC address filtering | |
| Authentication | Port-based authentication |
| IGMP snooping | |
| Access Control List (ACL) | |
| Loop protection | |
| Security algorithms | 802.1x RADIUS, SNMP, SSH, SSL/TLS |
| Management protocols | web, telnet, SNMP |
| Supported network protocols | IPv4 / IPv6 |
| Rack mounting | |
| Form factor | 1U |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Certification | FCC, CE |
| Firmware upgradeable |
| Power consumption (max) | 8.2 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Power over Ethernet (PoE) |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Storage relative humidity (H-H) | 5 - 95 % |
| Heat dissipation | 30 BTU/h |
| Width | 217 mm (8.46 ") |
| Depth | 135 mm (5.27 ") |
| Height | 43.5 mm (1.7 ") |
| Weight | 853 g (1.88 lbs) |
