Cambium Networks cnMatrix Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Grey
Eligible for Free Shipping & Free Returns
MPN
MX-EX2028XXA-U
About this item
Cloud managed, 24 x Gigabir Ethernet ports, 4 x SFP+
Improve network performance while reducing the time and cost of provisioning and management
cnMatrix™ EX2028 switch simplifies network deployment and operation. When deployed with cnPilot™ WLAN access points and the cnMaestro™ management system, network operators have an affordable, feature rich, high quality unified wired/ wireless enterprise grade network. Improve performance, security and end user satisfaction while reducing costs with cnMatrix EX2028.
Specifications
Management features
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | |
| System event log | |
| Web-based management | |
| Reset button | |
| Configuring Location Settings (CLI) | |
| ARP inspection |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP+ modules quantity | 4 |
| Console port | RS-232 |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Gigabit Ethernet (copper) ports quantity | 24 |
| USB 2.0 ports quantity | 1 |
Networking
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x |
| Head-of-line (HOL) blocking | |
| Port mirroring | |
| Auto MDI/MDI-X | |
| Link aggregation | |
| Rate limiting | |
| Broadcast storm control | |
| Spanning tree protocol | |
| Virtual LAN features | Port-based VLAN, Tagged VLAN |
Data transmission
| Switching capacity | 128 Gbit/s |
| MAC address table | 1600 entries |
| Number of queues | 8 |
| Static route | |
| Number of static routes | 64 |
| Jumbo frames support | |
| Jumbo frames | 9000 |
Virtual LAN features
| VLAN support |
Multicast features
| Multicast support |
Security
| DHCP features | DHCP snooping |
| Queue scheduling algorithms | SP, Weighted Round Robin (WRR) |
| Access Control List (ACL) | |
| Security algorithms | 802.1x RADIUS, SSH |
| MAC address filtering | |
| Password protection | |
| Authentication type | AAA, RADIUS |
| BPDU filtering/protection | |
| Authentication | MAC-based authentication, Port-based authentication |
Design
| Rack mounting | |
| Form factor | 1U |
| Product colour | Grey |
| LED indicators | Y |
Performance
| Processor frequency | 800 MHz |
| Internal memory | 512 MB |
| Flash memory | 128 MB |
| Mean time between failures (MTBF) | 432283 h |
Power
| Power supply included | |
| AC input voltage | 100 - 240 V |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Width | 440 mm (17.16 ") |
| Depth | 209 mm (8.15 ") |
| Height | 44 mm (1.72 ") |
| Weight | 2770 g (6.11 lbs) |
Other features
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Y | |
| Y |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
MX-EX2028XXA-U by Cambium Networks
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
Similar Products
View More-
-
Hewlett Packard EnterpriseHPE Aruba Instant On 1930 48g Class4 PoE 4SFP/SFP+ 370w Switch 1U
$1,009.00 -
-
-
-
-
Hewlett Packard EnterpriseHewlett Packard Enterprise Aruba 6000 48G 4SFP Managed L3 Gigabit Ethernet (10/100/1000) 1U (R8N86A#ABA)
$733.00 -
-
Aruba, a Hewlett Packard Enterprise companyAruba, a Hewlett Packard Enterprise company Aruba Instant On 1960 24G 2XGT 2SFP+ Managed L2+ Gigabit Ethernet (10/100/1000) 1U White (JL806A)
$886.00 -
-
BLACK BOX CORPORATIONCAT6 A/B SWITCH - LATCHING RJ-45 REMOTE CONTROL, DRY CONTACT, GSA, TAA, 45 DAY S (SW1040A)
