Gigabyte B760M DS3H DDR4 motherboard LGA 1700 micro ATX (B760M DS3H DDR4)

SKU

5304094

Be the first to review this product

$147.00

Visit our GIGABYTE Store

MPN

B760M DS3H DDR4

UPC

889523034606

6+2+1 Phases Hybrid Digital VRM Design

- 6+2+1 Phases Low RDS(on) MOSFETs
- Premium Choke and Capacitors to improve transient response and minimize oscillation

GIGABYTE Ultra-Efficient M.2 Thermal Guard

With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling and bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.

SMART FAN 6

Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface

PERSONALIZATION

GIGABYTE motherboards bundle several useful and intuitive software to help users to control every aspect of motherboard and provide customizable lighting effect with outstanding aesthetics to fit your unique personality.

ULTRA DURABLE

Q-Flash Plus

Update the BIOS easily without installing the CPU, memory and graphics card.
With GIGABYTE Q-Flash Plus, you don't need to install the CPU, memory and graphics card nor enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button and you’re good to go!

Specifications

Memory

Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Memory channels	Dual-channel
Non-ECC
Supported memory clock speeds	2133,2400,2666,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133,4266,4300,4400,4500,4600,4700,4800,4933 MHz
Maximum internal memory	128 GB
Unbuffered memory

Processor

Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
Processor socket	LGA 1700

Storage controllers

Supported storage drive types	HDD & SSD
RAID levels	0,1,5,10

Internal I/O

USB 2.0 connectors	2
USB 3.0 (3.1 Gen 1) connectors	1
Supported storage drive interfaces	M.2, SATA III
Number of SATA III connectors	4
S/PDIF out connector
Front panel audio connector
Front panel connector
ATX Power connector (24-pin)
CPU fan connector
Number of chassis fan connectors	3
EPS power connector (8-pin)
Serial port headers	1
TPM connector
Parallel connector
RGB LED pin header

Back panel I/O ports

PS/2 ports quantity	1
VGA (D-Sub) ports quantity	1
HDMI ports quantity	1
DisplayPorts quantity	2
Headphone outputs	1
USB 3.0 (3.1 Gen 1) Type-A ports quantity	3
USB 2.0 ports quantity	2
USB 3.1 (3.1 Gen 2) Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	1

Networking

Ethernet LAN
Ethernet interface type	2.5 Gigabit Ethernet

Features

Supported processor sockets	LGA 1700
PC health monitoring	FAN, Temperature, Voltage, Water cooling
Component for	PC
Motherboard chipset family	Intel
Motherboard form factor	Micro ATX
Audio output channels	7.1 channels
Windows operating systems supported	Windows 10, Windows 11

Graphics

HDCP
Number of displays supported	4
Maximum resolution	4096 x 2304 pixels
Parallel processing technology support	Not supported

Expansion slots

PCI Express x16 (Gen 3.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
Number of M.2 (M) slots	1

BIOS

BIOS type	UEFI AMI
Desktop Management Interface (DMI) version	2.7
ACPI version	5.0
System management BIOS (SMBIOS) version	2.7
Clear CMOS jumper
BIOS memory size	128 MB

Power

Power source type

ATX

Weight & dimensions

Width	244 mm (9.52 ")
Depth	244 mm (9.52 ")

Packaging content

Bundled software

Norton Internet Security

Other features

	Y
	4933
	Y
	6
