Hanwha XNB-9003 security camera Box IP security camera Indoor & outdoor 3840 x 2160 pixels Ceiling/wall
About this item
1/1.8" CMOS, 4K, 0.03Lux, 120 fps, H.265/H.264, Day & Night (ICR), extremeWDR, PoE
1/1.8" CMOS, 4K, 0.03Lux, 120 fps, H.265/H.264, Day & Night (ICR), extremeWDR, PoE
Specifications
Performance
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| PTZ control (Pan/Tilt/Zoom) | |
| PTZ modes | Digital PTZ, Preset point |
| People counting function | |
| Wide Dynamic Range (WDR) | |
| Day/night mode | |
| Number of languages | 17 |
| Dynamic range | 120 dB |
| Languages support | CHI (SIMPL), CZE, DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR |
| Infrared (IR) cut-off filter |
Design
| Form factor | Box |
| Product colour | Black |
| Mounting type | Ceiling/Wall |
| Housing material | Aluminium |
Video
| Maximum resolution | 3840 x 2160 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Video compression formats | H.264, H.265, M-JPEG |
| Video intelligence analytic | |
| Supported graphics resolutions | 320 x 240,640 x 360,640 x 480 (VGA),720 x 480,720 x 576,800 x 448,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2592 x 1944,2688 x 1520,3072 x 1728,3840 x 2160 |
| Noise reduction | |
| Back Light Compensation (BLC) | |
| Flip & mirror | |
| Privacy masking | |
| Image stabilizer | |
| Video streaming | |
| Frame rate | 120 fps |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
Camera
| Minimum illumination | 0.03 lx |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/12000 s |
Image sensor
| Number of sensors | 1 |
| Sensor type | CMOS |
| Optical sensor size | 1/1.8 " |
Security
| Alarm input channels | 2 |
| IP address filtering | |
| Anti-flicker | |
| Video motion detection | |
| Active tampering alarm | |
| HTTPS encryption |
Storage
| Card reader integrated | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 512 MB |
| Maximum memory card size | 512 GB |
Night vision
| Night vision |
Networking
| Ethernet LAN | |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast |
| Streaming method | Multicast, Unicast |
| Quality of Service (QoS) support | |
| Number of users | 20 user(s) |
Ports & interfaces
| Connectivity technology | Wired |
| USB port | |
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Audio
| Audio input channels | 1 |
| Audio output channels | 1 channels |
| Audio detection | |
| Audio formats supported | AAC-LC, ADPCM, G.711, G.711 μ-law, G.726 |
Weight & dimensions
| Width | 81 mm (3.16 ") |
| Depth | 165 mm (6.44 ") |
| Height | 67 mm (2.61 ") |
| Weight | 880 g (1.94 lbs) |
Power
| Power source type | DC, PoE |
| Power consumption (max) | 19 W |
| DC output voltage | 12 |
| Power consumption (Power over Ethernet (PoE)) | 12.9 W |
| Power consumption (typical) | 9.5 W |
Management features
| Web browser |
Operational conditions
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -50 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage relative humidity (H-H) | 0 - 90 % |
Packaging content
| Number of cameras | 1 |
