Intel Core i5-14400F processor 20 MB Smart Cache
Eligible for Free Shipping & Free Returns
MPN
CM8071504821113
About this item
Intel® Core™ i5 processor 14400F (20M Cache, up to 4.70 GHz) FC-LGA16A, Tray
Intel® Core™ i5 processor 14400F (20M Cache, up to 4.70 GHz) FC-LGA16A, Tray
Specifications
Processor
| Processor manufacturer | Intel |
| Processor generation | Intel Core i5-14xxx |
| Processor family | Intel Core i5 |
| Processor cores | 10 |
| Processor socket | LGA 1700 |
| Processor model | i5-14400F |
| Processor threads | 16 |
| Performance cores | 6 |
| Efficient cores | 4 |
| Processor operating modes | 64-bit |
| Performance-core boost frequency | 4.7 GHz |
| Performance-core base frequency | 2.5 GHz |
| Efficient-core boost frequency | 3.5 GHz |
| Efficient-core base frequency | 1.8 GHz |
| Processor cache | 20 MB |
| Processor cache type | Smart Cache |
| Box | |
| Maximum turbo power | 148 W |
| Processor base power | 65 W |
| Processor boost frequency | 4.7 GHz |
| Processor codename | Raptor Lake |
| Stepping | B0 |
| Maximum number of DMI lanes | 8 |
| Processor ARK ID | 236777 |
Memory
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 76.8 GB/s |
Graphics
| On-board graphics adapter | |
| Discrete graphics adapter | |
| On-board graphics adapter model | Not available |
| Discrete graphics adapter model | Not available |
Features
| Idle States | |
| Thermal Monitoring Technologies | |
| Execute Disable Bit | |
| Use conditions | PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0,5.0 |
| PCI Express configurations | 1x16+1x4,2x8+1x4 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | |
| Direct Media Interface (DMI) Revision | 4.0 |
| Scalability | 1S |
| Market segment | Desktop |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Processor special features
| Intel® Hyper Threading Technology (Intel® HT Technology) | |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | |
| Intel® Speed Shift Technology | |
| Enhanced Intel SpeedStep Technology | |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | |
| Intel® Control-flow Enforcement Technology (CET) | |
| Intel® Thread Director | |
| Intel® Boot Guard | |
| Mode-based Execute Control (MBE) | Y |
| Intel 64 | |
| Intel® Secure Key | |
| Intel Virtualization Technology (VT-x) | |
| Intel® OS Guard | |
| Intel VT-x with Extended Page Tables (EPT) | |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Intel® Standard Manageability (ISM) | |
| Intel® Deep Learning Boost (Intel® DL Boost) | |
| Intel® Volume Management Device (VMD) |
Operational conditions
| Tjunction | 100 °C |
Technical details
| Status | Launched |
| Launch date | Q1'24 |
Weight & dimensions
| Processor package size | 45 x 37.5 mm |
Other features
| L2 cache | 9728 KB |
| Maximum internal memory | 192 GB |
