iogear GCS1964 KVM switch Black
About this item
GCS1964, HDMI, DP, USB, 3.5mm, RJ-45, DC 12V, 57x155.6x336.6 mm
Enhance Your High-End Multi-Monitor Workstation
Maximize your high-end triple DisplayPort workstations by connecting them to the 4-Port 4K Triple View Display Port KVMP. Experience 4K Cinema resolutions along with rich bass and 7.1 surround sound while switching between both computers and sharing two USB 3.0 peripherals with the push of a button. Now with Video DynaSync support, switching between computers will be faster than generic DisplayPort KVMs, optimizing workflow and efficiency.
A Triple Cinema 4K Experience
Join three Cinema 4K HDMI monitors to your premium desktop or laptop to experience superior screen, image, and video quality. The Triple View DisplayPort KVMP delivers a Cinema 4K resolution standard of 4096 x 2160 at a frame rate of 60Hz.
Designed for healthcare imaging, engineering and finance industries, this 4-Port KVMP supports environments requiring cinematic graphics resolution. Superior quality is also ideal for applications in architecture, video production and media design.
Convenient Switching Methods
Switch and access four DisplayPort computers from the push-button front panel or hotkey combination on your keyboard. Utilize the latest in mouse port-switching functionality to change ports by merely clicking the wheel button on your 3-button USB mouse.
Expand to Utilize Up to Six 4K Monitors
Tackle large projects and double your desktop viewing space by adding a second 4-Port KVMP (GCS1964). Expand your workstations to accommodate up to six 4K HDMI monitors. The Triple View is the perfect solution for clinical diagnostic imaging where each workstation involves various diagnostic equipment used together and where diagnostic displays can be spread among multiple Cinema 4K monitors for clearer, more precise readings. This function also serves engineers who need to see a complete construction life cycle shown across multiple 4K monitors for improved detail viewing; thus, optimizing workflow.
Smart Connectivity
Additional smart connectivity features turn your workstation into a convenient, easy-to-use powerhouse. The Power-on Detection ensures automatic connection to the next powered-on computer. With Daisy-Chain Connection (DCC) support, double your desktop viewing space by cascading two GCS1964 together, accommodating up to six 4K HDMI monitors. The built-in USB 3.0 ports provide connectivity speeds up to 5 Gbps and compatibility with legacy USB 2.0 and 1.1 devices, allowing for maximum efficiency when testing source codes of various imaging software.
Specifications
Video
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
| Video bandwidth | 60 Hz |
Ports & interfaces
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| HDMI ports quantity | 3 |
| DisplayPorts quantity | 12 |
| USB 3.0 (3.1 Gen 1) Type-B ports quantity | 4 |
| Console ports | 3.5mm headphone,3.5mm mic, HDMI, USB A |
| Console USB ports quantity | 2 |
| Serial port type | RJ-45 |
| Serial ports quantity | 1 |
| Audio connections | |
| Headphone outputs | 5 |
| Number of microphone inputs | 5 |
| DC-in jack |
Performance
| Scan interval | 1,99 s |
Design
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Push button | |
| Hot keys |
Power
| Power source | DC |
| DC input voltage | 12 V |
| Power consumption (typical) | 15.49 W |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Storage relative humidity (H-H) | 0 - 80 % |
Weight & dimensions
| Width | 336.6 mm (13.13 ") |
| Depth | 155.6 mm (6.07 ") |
| Height | 57 mm (2.22 ") |
| Weight | 1950 g (4.3 lbs) |
Packaging data
| Package width | 546.1 mm |
| Package depth | 120.7 mm |
| Package height | 266.7 mm |
| Package weight | 3790 g |
Packaging content
| Cables included | Audio (2.5mm), DisplayPort, USB |
| AC adapter included | |
| Quick installation guide |
Logistics data
| Master carton width | 565 mm |
| Master carton length | 387.4 mm |
| Master carton height | 266.7 mm |
| Master carton weight | 11730 g |
| Quantity per master carton | 3 pc(s) |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
GCS1964 by iogear
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
