Axis M2026-LE MK II IP Security Outdoor/Indoor Bullet Camera

Out of stock
SKU
15_01049-001_1
Special Price $397.88 Regular Price $510.00
MPN
01049-001
UPC
7331021058491

About this item
  • Outdoor-Ready;
  • 1/3" CMOS, 4 MP, 2688x1520;
  • PoE, Digital PTZ,IR, Zipstream, microSD;
  • 1 x 10/100 Mb/s RJ-45;
  • White;

The Axis M2026-LE Mk II Network Camera is a small bullet camera that provides outstanding performance at an affordable price.

This 4MP / Quad HD 1440p camera comes with built-in IR illumination, and you can use it indoors and outdoors.

The camera is available in white.

Excellence at an affordable price with Axis

Axis M2026-LE MK II Network Camera provides high-resolution surveillance even in the dark thanks to its built-in IR LEDs and 4 MP / Quad HD 1440p image quality.

The cost of using a single Axis IP camera is kept low thanks to its 130° wide field of view.

WDR - Dynamic Capture takes advantage of backlighting to optimize video footage.

Axis Corridor Format offers optimal image quality and eliminates bandwidth and storage waste when monitoring long, narrow areas.

Furthermore, Axis Zipstream technology reduces storage and bandwidth usage while maintaining a high degree of image quality.

There are two video compression formats supported by the camera: H.264 and H.265.

Top performance in tough environments

In operation, the M2026-LE Mk II can withstand temperatures of -30 °C to 50 °C (-22 °F to 122 °F).

An integrated sunscreen keeps you protected from the sun and the rain.

In addition, it's resistant to rough weather, dust, sand and salt spray, ice formation, and high water pressure thanks to its IP66 and NEMA 4X ratings.

Simple installation that takes just a few minutes

The M2026-LE Mk II is easy - and cost-efficient - to install because it is small, lightweight and factory-focused.

With a spacious, sealed back box, cables are protected, while service is made easy.

It is easy to handle, and its wide field of view means that it can be placed outdoors or indoors, on walls, ceilings, poles, or even in corners.

For extra-discreet surveillance, install on a wall or ceiling using the optional recessed mount.

Specifications
Performance
Type IP security camera
Placement supported Outdoor
PTZ modes Digital PTZ
Auto-tracking
Wide Dynamic Range (WDR)
Day/night mode
Infrared (IR) cut-off filter
Number of languages 11
Languages support CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, POR, RUS
Design
Form factor Bullet
Product colour White
Mounting type Ceiling/Wall
International Protection (IP) code IP66
Weatherproof
Housing material Polymer
Video
Maximum resolution 2688 x 1520 pixels
Total megapixels 4 MP
Video compression formats H.264, H.265, M-JPEG, MPEG4
Supported graphics resolutions 320 x 240,2688 x 1520
Supported video modes 1440p
Privacy masking
Text caption overlay
Image quality adjustment Brightness, Contrast, Sharpness
Video streaming
Camera
Viewing angle, horizontal 130 °
Viewing angle, vertical 73 °
White balance Yes
Camera shutter speed 1/31500 - 1/5 s
Image sensor
Progressive scan
Sensor type CMOS
Optical sensor size 1/3 "
Lens system
Fixed focal length 2.4 mm
Focus adjustment 2.2
Security
Password protection type User
Video motion detection
HTTPS encryption
Security algorithms 802.1x RADIUS, HTTPS, SSH, SSL/TLS
Active tampering alarm
IP address filtering
Alert notification type E-mail
Storage
Card reader integrated
Compatible memory cards MicroSD (TransFlash), MicroSDHC, MicroSDXC
Built-in hard drive
Internal memory 512 MB
Flash memory 256 MB
Night vision
Night vision
Night vision distance 15 m
LED type IR
Infra-red wavelength 850 nm
Networking
Ethernet LAN
Ethernet interface type Fast Ethernet
Cabling technology 10/100Base-T(X)
Wi-Fi
Networking standards IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP TM , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Quality of Service (QoS) support
3G
4G
Ports & interfaces
Connectivity technology Wired
USB port
Ethernet LAN (RJ-45) ports 1
Weight & dimensions
Height 174 mm (6.79 ")
Diameter 101 mm
Weight 500 g (1.1 lbs)
Power
Power source type PoE
Power over Ethernet (PoE)
Power consumption (typical) 5.1 W
Power consumption (max) 7.9 W
Certificates
Certification EN 55032 Class A, EN 55024, IEC 62471, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35 IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-78, IEC 60068-2-14, IEC 60068-2-6, IEC 60068-2-27, IEC/EN 62262 IK08, IEC/EN 60529 IP66, NEMA 250 Type 4X
Operational conditions
Operating temperature (T-T) -30 - 50 °C
Storage temperature (T-T) -40 - 65 °C
System requirements
Windows operating systems supported Y
Packaging content
Quick installation guide
Number of cameras 1
Technical details
Lens mount interface M12
Removable IR-cut filter
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 01049-001 by Axis you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
