NetGear Insight Instant Mesh Multi-Mode Access Point

SKU

6_WAC564-100NAS_1

Be the first to review this product

$133.00

Visit our Netgear Store

MPN

WAC564-100NAS

UPC

606449142068

Netgear Insight Instant Mesh Multi-Mode Access Point WAC564-100NAS is centralized and comes with an integrated 4-port Ethernet switch

HIGH-DENSITY MESH PERFORMANCE

First instant mesh wireless multi-mode access point on the market now available

Netgear Insight Instant Mesh Multi-Mode Access Point WAC564-100NAS is innovative gadget that functions as a mesh extender or access point.

The WAC540 and WAC564 are compatible with instant mesh extender mode

Tri-Band AC3000 speed, coupled with MU-MIMO technology, improves WiFI performance for up to 600 devices where no Ethernet cabling exists - WAC540 required for Mesh network.

WIRED ETHERNET PORT

Plug in a printer, storage, or other nearby wired devices into the four 1 Gigabit ports for maximum speed.

AC POWERED

Simplifed deployment powered by the included power adapter.

LOCAL AND REMOTE MANAGEMENT

Includes 1 year FREE Insight subscription for remote management from anywhere, and no additional hardware or cloud key required. Setup, configure, and manage with the Insight app.

FLEXIBLE MOUNTING

Easy to securely install on the wall or a suspended ceiling with included hardware, or place on a tabletop

Installs Anywhere

Versatile housing design conveniently installs on the wall, ceiling T-bar frame, or sits on a desktop.

It works wherever no Ethernet cable is available - when used with WAC540, sold separately.

Smart Roaming with Mesh Technology

Simplify and stay connected with one network name and auto-switching to the best network across all devices.

Wired Ethernet Connections

Four 1G Ethernet ports connect printers, storage, and other nearby devices.

Specifications

Performance

Ethernet LAN data rates	10,100,1000 Mbit/s
Data transfer rate (max)	1733 Mbit/s
2.4 GHz
5 GHz
Number of users	600 user(s)
MIMO
MIMO type	Multi User MIMO
Wi-Fi Roaming
Band Steering
Airtime Fairness (ATF)
Remote Authentication Dial-In User Service (RADIUS)
Web-based management
Auto MDI/MDI-X
VLAN support
Auto Wireless Distribution System (WDS)
Wi-Fi Multimedia (WMM)/(WME)
Modulation	256-QAM
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Reset button
Certification	CE

Ports & interfaces

Ethernet LAN (RJ-45) ports	4
DC-in jack

Security

Security algorithms	EAP-TLS, PEAP, SNMP, SSH, SSID, SSL/TLS, TTLS, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
MAC address filtering
VPN support	ProSUPPORT

Antenna

Antenna type	Internal
Antenna features	Integrated antenna
Antenna gain level (max)	4 dBi

Power

Input voltage	12 V
Input current	3.5 A
Power over Ethernet (PoE)

Design

Product colour	White
LED indicators	LAN, Power, WLAN
Placement	Ceiling, Wall

Features

Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Throughput data rate	3000 Mbit/s
Fit AP mode features	802.11k & 802.11v smart roaming, Wireless distribution system (WDS)
WLAN channel features	WLAN channel management

Software

Access Control List (ACL)
Adaptive bandwidth management

Weight & dimensions

Width	174 mm (6.79 ")
Depth	85 mm (3.32 ")
Height	247 mm (9.63 ")
Weight	930 g (2.05 lbs)
Package width	262 mm
Package depth	220 mm
Package height	166 mm
Package weight	1870 g

Packaging content

Mounting kit
Quick start guide
Package type	Box
Number of products included	1 pc(s)

Logistics data

Master carton width	242 mm
Master carton length	356 mm
Master carton height	330 mm
Master carton weight	4400 g
Quantity per master carton	2 pc(s)
