Socket Mobile DuraScan D740 Handheld bar code reader 1D/2D LED White
Eligible for Free Shipping & Free Returns
MPN
CX3750-2402
UPC
758497117779
About this item
DuraScan D740, 1D/2D omni-directional LED, Bluetooth 2.1+EDR
The DuraScan D740 v20 is the latest and improved version of the universal Bluetooth® barcode scanner. Built for mobility and redesigned for improved durability, the D740 v20 is IP54 compliant, ideal for warehousing and manufacturing application customers. In addition, Socket Mobile has added a field-replaceable battery based on customer feedback. The scanner is MFi certified and fully compatible with Android and Windows with different Capture SDK versions available.
The D740 v20 reads all 2D/1D barcodes on paper and screen. It features great ergonomics and fits perfectly in your hand. It is designed for comfort and extended use; it is light, highly durable and small enough to fit in your pocket. The D740 v20 is fully backwards compatible with prior versions of Socket Mobile’s SDK and can be used immediately with any application using native scanning support. To enjoy optimal reliability and performance from the D740 v20, it is recommended that users check with their app provider to ensure they have upgraded to the latest version of Capture SDK.
The D740 v20 reads all 2D/1D barcodes on paper and screen. It features great ergonomics and fits perfectly in your hand. It is designed for comfort and extended use; it is light, highly durable and small enough to fit in your pocket. The D740 v20 is fully backwards compatible with prior versions of Socket Mobile’s SDK and can be used immediately with any application using native scanning support. To enjoy optimal reliability and performance from the D740 v20, it is recommended that users check with their app provider to ensure they have upgraded to the latest version of Capture SDK.
Specifications
Scanning
| Optical sensor resolution (W x H) | 640 x 400 pixels |
| Scanner type | 1D/2D |
| Sensor type | LED |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, Discrete 2 of 5, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 Databar Limited, ISSN, Interleaved 2 of 5, JAN, MSI, Matrix 2 of 5, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code |
| Light levels (direct sunlight) | 0 - 100000 lx |
Ports & interfaces
| Connectivity technology | Wireless |
| Standard interfaces | Bluetooth |
| Wireless range | 30 m |
| Bluetooth version | 2.1+EDR |
Design
| Type | Handheld bar code reader |
| International Protection (IP) code | IP54 |
| LED indicators | Y |
| Product colour | White |
| RoHS compliance |
Power
| Power source type | Battery |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 1500 mAh |
| Number of reads per charge | 70000 |
| Battery life | 25 h |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -5 - 70 °C |
Weight & dimensions
| Width | 37.1 mm (1.45 ") |
| Depth | 40.1 mm (1.56 ") |
| Height | 132.2 mm (5.16 ") |
| Weight | 109 g (0.24 lbs) |
