StarTech.com 8 Port Rackmount USB VGA KVM Switch w/ Audio (Audio Cables Included)

In stock
Only 5 left
SKU
14_SV831DUSBAU_1
$541.00
Eligible for Free Shipping & Free Returns
MPN
SV831DUSBAU
UPC
065030837248
About this item
StarTech.com 8 Port Rackmount USB VGA KVM Switch w/ Audio (Audio Cables Included)
The SV831DUSBAU 8 Port Rack Mount USB VGA KVM Switch (with Audio Cables Included) allows you to control up to 8 USB computers using a single keyboard, mouse and monitor, and features Audio and Microphone ports to switch between audio signals as well as PC ports.
Based on a 1U rack mountable slim form factor design, this 8 Port USB KVM uses rear cable connections to maximize space efficiency. Multiple KVM units can also be connected (cascaded) together for control of up to 64 computers, ensuring a scalable KVM solution that can be expanded as necessary.
To ensure seamless operation, the switch features automatic and manual scan modes, supports both hot-key and front panel push-button switching, and features a convenient OSD (on-screen display) for added configuration options.
Backed by a StarTech 3-year warranty and free lifetime technical support.

The StarTech Advantage

- Rugged, rack mountable 1U metal chassis is ideal for any environment
- User friendly access through the OSD saves configuration time and frustration
- Extracting the keyboard strokes from the USB connection this KVM enables hot key support for wireless keyboard and mouse combo kits that use a single USB receiver
Specifications
Video
Maximum resolution 1920 x 1440 pixels
Maximum analog resolution 1920 x 1440 pixels
Ports & interfaces
Number of computers controlled 8
Keyboard port type USB
Mouse port type USB
Video port type VGA
Console ports 3.5mm headphone,3.5mm mic, USB A, VGA (D-Sub)
Console USB ports quantity 2
USB 2.0 ports quantity 2
USB connector type USB Type-A
Headphone outputs 8
Number of microphone inputs 8
DC-in jack
Performance
Plug and Play
Daisy chain
Number of users 1 user(s)
Design
Rack mounting
Rack capacity 1U
Product colour Black
Material Steel
Cascadable
LED indicators Y
RoHS compliance
Certification CE, FCC, UL
Display
On Screen Display (OSD)
Power
AC input voltage 110-240 V
Input current 1.8 A
Output voltage 12 V
Output current 4 A
Power consumption (typical) 48 W
Plug type Type M
Operational conditions
Operating temperature (T-T) 5 - 40 °C
Storage temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 0 - 80 %
Weight & dimensions
Width 540 mm (21.06 ")
Depth 180 mm (7.02 ")
Height 45 mm (1.76 ")
Weight 2600 g (5.73 lbs)
Packaging data
Package width 123 mm
Package depth 591 mm
Package height 264 mm
Package weight 4700 g
Packaging content
Cables included AC
Manual
Rubber feet
AC adapter included
Other features
Audio support
IP control N
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for SV831DUSBAU by StarTech.com you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
