Unitech MS838B Handheld bar code reader 1D/2D CMOS Black
Eligible for Free Shipping & Free Returns
MPN
MS838-2UBB0D-SG
About this item
2.4G Wireless 2D Imager Scanner, 100 M Connection | Keeps data even out of range | 16 hours operation time
Delivering reliable performance and affordable price, the MS838B wireless 2D imager scanner combines superior 1D and 2D barcode scanning with the freedom of wireless technology. The well-integrated mobility design allows users to move around without being restricted, while supporting high comfort over long periods of operation. This cost-effective and reliable handheld scanner provides the optimum combination of performance that makes it an ideal scanning tool for a wide range of market applications, such as point-of-sale, personal data identification and inventory control.
Specifications
Scanning
| Optical sensor resolution (W x H) | 640 x 480 pixels |
| Scanner type | 1D/2D |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 Databar Limited, GS1-128 (UCC/EAN-128), Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Micro QR Code, MicroPDF417, PDF417, QR Code |
| Sensor type | CMOS |
| Pitch reading angle | -65 - 65 u00b0 |
| Light levels (direct sunlight) | 0 - 10000 lx |
Ports & interfaces
| Connectivity technology | Wired & Wireless |
| Standard interfaces | USB |
| Operating frequency | 2400 MHz |
Design
| Type | Handheld bar code reader |
| International Protection (IP) code | IP54 |
| LED indicators | Y |
| Product colour | Black |
Performance
| Buzzer | |
| Internal memory | 16 MB |
Power
| Power source type | USB |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 2600 mAh |
| Battery voltage | 5 V |
| Battery life | 16 h |
| Charging time | 6 h |
| Power consumption | 250 mA |
Operational conditions
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
Weight & dimensions
| Width | 170 mm (6.63 ") |
| Depth | 75 mm (2.93 ") |
| Height | 102 mm (3.98 ") |
| Weight | 200 g (0.44 lbs) |
Packaging content
| Cables included | USB |
