Viewsonic TD2223 touch screen monitor 54.6 cm (21.5") 1920 x 1080 pixels Multi-touch Multi-user

In stock

SKU

9_TD2223_1

Be the first to review this product

$305.00

Visit our Viewsonic Store

MPN

TD2223

UPC

766907008647

About this item

21.5", 1920x1080, 16:9, TN, VGA, USB, HDMI, DVI-D, 521x334x101 mm

Description
Specifications

The ViewSonic TD2223 is a 22” IR touch display designed for intuitive multi-touch use. Infrared (IR) touchscreen can detect up to 10 points of contact compared to optical touchscreens and can be operated by a stylus, fingers and gloved hands. The multi-touch input is more accurate, and the display is faster. Coupled with an adjustable tilt, you can easily interact with the TD2223 at an ideal position. This monitor features Full HD resolution to give you clear images and is built with scratch-resistant 7H hardness screen to surface damage. To support your work, the TD2223 is equipped with VGA, HDMI, DVI and USB connectivity.

Intuitive Multi-touch Experience

An infrared touchscreen that can detect up to 10 points of contact under Windows compared to optical touchscreens, the TD2223 delivers an intuitive multi-touch experience with every tap, pinch, and swipe.

Operating System Support

This monitor supports the main operating systems being Windows, macOS, Android, Chrome OS, Linux and Raspberry Pi.

Simple and Safer Way to Interact

This monitor can be operated by stylus and gloved hands, which improves hygiene and is effective for selection, dragging, and drawing. What’s more, there is a magnetic pen placeholder on the base.

Anti-scratch Touchscreen

With a built-in 7H hardness screen, it’s resistant to surface damage caused by sharp objects.

Adjustable Tilt

This monitor includes an adjustable tilt, which allows you to easily tilt back up to 40-degrees, making it a good fit for anyone.

Clear Images

This monitor features Full HD 1920x1080 resolution to benefit you with greater image details and more displayable on-screen contents.

Dual Integrated Speakers

With built-in 2-watt speakers, this monitor provides you a better audiovisual experience.

Enhanced Viewing Comfort

This monitor is built with Flicker-Free technology and a Blue Light Filter to reduce eye fatigue after a long day of use.

Specifications

Display

Display diagonal	21.5 "
Display resolution	1920 x 1080 pixels
Panel type	TN
HD type	Full HD
Display technology	LED
High frequency rate	75 Hz
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Display number of colours	16.78 million colours
Display brightness	250 cd/m²
Viewing angle, horizontal	170 \u00b0
Contrast ratio (typical)	1000:1
Touchscreen technology	Infrared
Viewing angle, vertical	160 \u00b0
Contrast ratio (dynamic)	20000000:1
Response time	5 ms
Pixel pitch	0.248 x 0.248 mm
Horizontal scan range	24 - 82 kHz

Design

Product colour	Black
Glass thickness	2 mm

Performance

Touch technology	Multi-touch
Touchscreen type	Multi-user
Built-in camera
Built-in microphone
Built-in speaker(s)
RMS rated power	4 W
Number of simultaneous touchpoints	10
Number of speakers	2

Ports & interfaces

USB 2.0 ports quantity	3
HDMI version	1.4
DVI port
VGA (D-Sub) ports quantity	1
Headphone outputs	1
Cables included	AC, Audio (3.5mm), HDMI, USB Type-A to USB Type-B
HDMI ports quantity	1
DVI-D ports quantity	1

Ergonomics

Cable lock slot type	Kensington
Wall mountable
Cable lock slot
Tilt angle range	22 - 38 \u00b0
VESA mounting interfaces	100 x 100 mm

Power

Power supply type	AC
Power consumption (max)	14 W
Power consumption (typical)	12.5 W
Power consumption (standby)	0.5 W
AC input voltage	100-240 V
AC input frequency	50/60 Hz

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90 %

Certificates

Certification

cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, GEMS, PSE, CCC, China RoHS, China Energy Label, CECP

Packaging data

Stand included
Package width	580 mm
Package depth	164 mm
Package height	405 mm
Package weight	6000 g

Other features

Height (with stand)	334 mm
Depth (with stand)	101 mm
	Y
	Y
	61
	Y
	521
	318
	Y
	14
	4500
	ENERGY STAR, REACH, RoHS
	521
	3900
	Y
	E
