Aten CS1732B Grey KVM switch
About this item
2-Port USB - PS/2 VGA KVM Switch with Audio & USB 2.0 Hub (KVM Cables included)
Features
- 2-port KVM switch with USB 2.0 support and 2.1 surround sound audio
- One console controls two computers and two additional USB devices
- 2-port USB 2.0 hub built in
- USB 2.0 compliant
- Dual interface
- supports computers with PS/2 or USB keyboard and mouse configurations
- Audio enabled
- full bass response provides a rich experience for 2.1 surround sound systems
- Console audio ports on front panel for easy access
- ideal for IP phone users
- Supports both USB and PS/2 keyboards and mice
- flexible configurations available with the included USB-to-PS/2 converter: USB keyboard and mouse; PS/2 keyboard and mouse; or PS/2 keyboard and USB mouse
- Independent switching of KVM, USB, and Audio focus
- Superior video quality; 2048 x 1536; DDC2B
- Supports widescreen resolutions
- Computer selection via front panel pushbuttons, multilingual OSD (On Screen Display), and mouse
- Multiplatform support
- Windows , Mac, and Sun
- Console mouse port emulation / bypass feature supports full mouse driver and multifunction mice
- Video DynaSync™
- stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
- Complete keyboard emulation for error-free booting
- Sun/Mac keyboard support and emulation*
- Auto Scan Mode for monitoring all computers
- LED Display for easy status monitoring
- Easy installation no software required
- Firmware upgradeable
* 1.PC keyboard combinations emulate Sun/Mac keyboards
* 2.Sun/Mac keyboards only work with their own computers
Package Contents
- 1x 2-Port USB 2.0 KVMP™ Switch
- 2x 2L-5301U USB KVM Cables
- 1x UC20KMZ-A-11 USB-to-PS/2 Converter
- 2x OSD/Hotkey Stickers
- 1x Firmware Upgrade Cable
- 1x 0AD6-1605-24EG Power Adapter
- 1x User Instructions
Specifications
Ports & interfaces
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| Headphone outputs | 2 |
| Number of microphone inputs | 2 |
Design
| Product colour | Grey |
Display
| Display | LED |
Power
| Power consumption (typical) | 3.1 W |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 0 - 80 % |
Weight & dimensions
| Weight | 550 g (1.21 lbs) |
Other features
| Power supply type | 1 x DC Jack |
| Ports quantity | 2 |
| Compatible operating systems | -Windows 2000/XP/Vista -Linux -Mac -Sun |
| Dimensions (WxDxH) | 87 x 140 x 55 mm |
