be quiet! PURE BASE 501 Airflow Black Midi Tower

MPN
BG074
UPC
4260052191804

About this item
ATX / M-ATX / Mini-ATX, 1x USB Type-C, 2x USB Type-A, ATX PS/2, 2x Pure Wings 3 140mm PWM

Comfortably compact

Pure Base 501 Airflow Black is a traditional, timeless and versatile be quiet! ATX case with compact dimensions.


REDUCED TO THE MAX
Classic appearance

Without any distractions, Pure Base 501 Airflow Black is reduced to excel at its core functions and is aimed at users that appreciate an unagitated presentation.


PERFECT CASE FAN
Fan blades optimized for high airflow

With optimization for maximum airflow, Pure Wings 3 140mm PWM is the perfect choice for Pure Base 501 Airflow Black. Its 7 airflow-optimized fan blades not only reduce noise-generating turbulences but also ensure Pure Wings 3 140mm PWM provides the performance that is needed for demanding configurations.


MORE THAN MEETS THE EYE
Generous space for high-end hardware

Despite its compact dimensions, Pure Base 501 Airflow Black offers enough space for high-end graphics cards and large coolers. Triple fans or a radiator up to 360mm can be installed easily at the front, while the top area provides space for up to 2 fans or a radiator up to 240mm.


WAY UP!
With rotatable PCIe slots

Why not try something else with your GPU? The PCIe slots of the Pure Base 501 Airflow Black can be rotated 90° for an upright installation of wide high-end graphics cards. The spacing is perfect for the optional be quiet! Riser Cable, whose foam base provides excellent anti-sag support for graphics cards in vertical orientation.


INVENTORY MANAGEMENT
With smart cable routing options

As a compact PC case, Pure Base 501 Airflow Black optimally uses the offered space. Thanks to cleverly integrated cable routing options, it makes cable management a breeze.


CONNECT WITH ME
State-of-the-art technology for your system

A USB 3.2 Gen. 2 Type C connector and 2 Type A ports on the front I/O port for fast and easy connectivity.
Specifications
Design
Form factor Midi Tower
Type PC
Material Acrylonitrile Butadiene Styrene (ABS), Steel
Number of 5.25" bays 0
Number of 3.5" bays 2
Supported motherboard form factors ATX, Micro ATX, Mini-ITX
Product colour Black
Number of 2.5" bays 5
Anti-dust filter
Number of expansion slots 7
Maximum CPU cooler height 178 mm
Maximum PSU length 180 mm
Power supply
Power supply included
Supported power supply form factors ATX, PS2
Ports & interfaces
Audio input Y
Audio output Y
USB 2.0 ports quantity 0
USB 3.0 (3.1 Gen 1) Type-A ports quantity 0
USB 3.1 (3.1 Gen 2) Type-C ports quantity 1
USB 3.1 (3.1 Gen 2) Type-A ports quantity 2
Cooling
Front fans installed 1x 140 mm
Maximum front fans 3
Front fans diameters supported 120,140 mm
Rear fans installed 1x 140 mm
Maximum rear fans 1
Rear fans diameters supported 120,140 mm
Maximum top fans 2
Top fans diameters supported 120,140 mm
Maximum air pressure 0.96 mmH2O
Maximum airflow 57.4 cfm
Front radiator fan sizes supported 120,140,240,280,360 mm
Rear radiator fan sizes supported 120,140 mm
Top radiator fan sizes supported 120,240 mm
Pulse-width modulation (PWM) support
Storage
Supported hard disk drive sizes 2.5,3.5 "
Ergonomics
Reset button
On/off button
Weight & dimensions
Width 231 mm (9.01 ")
Depth 450 mm (17.55 ")
Height 463 mm (18.06 ")
Weight 6800 g (14.99 lbs)
Packaging data
Package width 292 mm
Package depth 518 mm
Package height 503 mm
Package weight 8000 g
Other features
CE, REACH, RoHS
