Panorama Antennas LGMTM-6-60-24-58 network antenna Omni-directional antenna 6 dBi
MPN
LGMTM-6-60-24-58
About this item
2x2MiMo (617-960/1710-6000MHz), WiFi, GPS/GNSS, 6 dBi, Omni-directional, IP69K
The L[G]M[H]M[B]-6-60-[24-58]
- "Great White" is a range of high-performance MiMo antennas covering 617-960/1710-6000MHz with optional GPS/GNSS and optional 2x2, 3x3 or 4x4 or 6x6 MiMo/Diversity at 2.4/5.0GHz.
The L[G]M[H]M[B]-6-60-[24-58] consists of up to 9 elements; two isolated high-performance antenna elements covering 617-960/1710-6000MHz offer MiMo/Diversity at cellular/LTE frequencies, up to 6 optional dual band elements covering 2.4 & 4.9-6GHz support MiMo/Diversity operation for WiFi and optional high-performance GPS/GNSS antenna with an integrated 26dB gain LNA and high-quality filtering offers un-paralleled positioning accuracy. None of the antennas in this range require a metallic ground plane, and all maintain a high level of performance even when mounted on non-metallic surfaces.
- "Great White" is a range of high-performance MiMo antennas covering 617-960/1710-6000MHz with optional GPS/GNSS and optional 2x2, 3x3 or 4x4 or 6x6 MiMo/Diversity at 2.4/5.0GHz.
The L[G]M[H]M[B]-6-60-[24-58] consists of up to 9 elements; two isolated high-performance antenna elements covering 617-960/1710-6000MHz offer MiMo/Diversity at cellular/LTE frequencies, up to 6 optional dual band elements covering 2.4 & 4.9-6GHz support MiMo/Diversity operation for WiFi and optional high-performance GPS/GNSS antenna with an integrated 26dB gain LNA and high-quality filtering offers un-paralleled positioning accuracy. None of the antennas in this range require a metallic ground plane, and all maintain a high level of performance even when mounted on non-metallic surfaces.
Specifications
Performance
| Frequency band | 0.617-0.96/1.71-6 GHz |
| Impedance | 50 Ω |
| Antenna gain level (max) | 6 dBi |
Features
| Antenna type | Omni-directional antenna |
| Voltage Standing Wave Ratio (VSWR) | <2.0:1 ± 4MHz |
| International Protection (IP) code | IP69K |
| Product colour | White |
Power
| Power consumption (max) | 20 W |
Operational conditions
| Operating temperature (T-T) | -40 - 80 °C |
Weight & dimensions
| Height | 75 mm (2.93 ") |
| Diameter | 176 mm |
Packaging content
| Quantity per pack | 1 pc(s) |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
LGMTM-6-60-24-58 by Panorama Antennas
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
