ACTi I96 2MP Outdoor Speed Dome with D/N
MPN
I96
UPC
888034003910
About this item
- 2 Megapixel with 1080p;
- Day & Night with Superior Low Light Sensitivity;
- 30x Zoom Lens with f4.3-129mm/ F1.6-5.0, DC iris, Auto Focus;
- Endless Pan & Tilt;
- Extreme WDR (107 dB);
- 30 fps at 1920 x 1080;
- Weatherproof (IP66) and Vandal Proof Options (IK10 or IK09);
ACTi I96 2-megapixel Day/Night HPoE Speed Dome PTZ IP Camera is equipped with a 30x optical zoom (4.3-129mm) and extreme WDR (Wide Dynamic Range).
A Progressive Scan CMOS image sensor is used in the I96 and Full HD images can be captured at resolutions of up to 1920 x 1080 pixels.
ACTi I96 has weather resistance (IP66 rating) and terminal blocks that can be used to connect an external power supply and digital input or output camera by ACTi.
- 2 Megapixel;
- 30x Optical Zoom (4.3-129mm);
- Endless Pan/Tilt;
- Day/Night with Mechanical IR Cut Filter;
- Superior Low Light Sensitivity;
- Extreme Wide Dynamic Range (WDR);
- 1/2.8" Progressive Scan CMOS Image Sensor;
- 30 fps at 1920 x 1080;
- H.264 / MJPEG Compression;
- MicroSDHC/MicroSDXC memory card slot;
- Two-way Audio;
- Video Motion Detection;
- IP66 rated Weatherproof;
- IK09 rated Vandal Resistant;
- High PoE / 24VAC;
Specifications
Performance
| Type | IP security camera |
| Placement supported | Outdoor |
| PTZ control (Pan/Tilt/Zoom) | |
| Wide Dynamic Range (WDR) | |
| Day/night mode |
Design
| Form factor | Dome |
| Product colour | White |
| Mounting type | Wall |
| Protection features | Vandal-proof, Water resistant |
| International Protection (IP) code | IP67 |
Video
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video formats supported | H.264, M-JPEG |
| Supported graphics resolutions | 320 x 240,1280 x 720 (HD 720),1920 x 1080 (HD 1080),640 x 480 (VGA) |
| Supported video modes | 1080p |
| Frame rate | 30 fps |
| Number of TV lines | 1800 |
Camera
| Minimum illumination | 0.1 lx |
| Viewing angle, horizontal | 66.4 \u00b0 |
| Tilt angle range | -20 - 200 \u00b0 |
| Tilt speed | 90 °/sec |
| Pan range | 0 - 360 \u00b0 |
| Pan speed | 90 °/sec |
| Camera shutter speed | 0.2 ~ 0.0005, 0.2 ~ 0.0001 s |
Image sensor
| Sensor type | CMOS |
| Progressive scan | |
| Optical sensor size | 1/2.8 " |
Lens system
| Zoom capability | |
| Optical zoom | 30 x |
| Digital zoom | 16 x |
| Focal length range (f-f) | 4.3 - 129 mm |
Security
| Password protection type | User |
| HTTPS encryption | |
| Video motion detection | |
| Security algorithms | 802.1x RADIUS, HTTPS |
| IP address filtering |
Storage
| Card reader integrated | |
| Compatible memory cards | MicroSDHC, MicroSDXC |
| Built-in hard drive |
Networking
| Ethernet LAN | |
| Cabling technology | 10/100Base-T(X) |
| Wi-Fi | |
| Supported network protocols | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour, Sony VISCA, Pelco D, Pelco P |
Ports & interfaces
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Interface | RJ-45 |
Audio
| Signal-to-Noise Ratio (SNR) | 56 dB |
| Audio formats supported | PCM |
| Audio system | 2-way |
Weight & dimensions
| Height | 276 mm (10.76 ") |
| Diameter | 200 mm |
| Weight | 2500 g (5.51 lbs) |
Power
| Power source type | PoE |
| AC input voltage | 24 V |
| Power over Ethernet (PoE) | |
| Power consumption (typical) | 31.5 W |
Management features
| Reset button |
Certificates
| Certification | CE, FCC, NEMA 4X |
Operational conditions
| Operating temperature (T-T) | -40 - 50 °C |
| Operating relative humidity (H-H) | 10 - 85 % |
Other features
| Compliance industry standards | 802.3at, 802.3, 802.3u |
| Power LED |
