APC Smart-UPS uninterruptible power supply (UPS) 3000 VA 10 AC outlet(s) Line-Interactive
SKU
14_SMX3000HV_1
Special Price
$2,844.72
Regular Price
$3,414.00
MPN
SMX3000HV
UPC
731304292616
About this item
Smart-UPS X 3000VA - LCD, 200-240V, 2700 W, 230V, 5% THD, SmartSlot, LED, 645 J, 4U, 38.64kg
APC Smart-UPS,2700 Watts /3000 VA,Input 208V, 230V /Output 230V, Interface Port SmartSlot, Extended runtime model, Rack Height 4 U
Includes: CD with software, Documentation CD, Rack Mounting brackets, Smart UPS signalling RS-232 cable, USB cable, User Manual
Includes: CD with software, Documentation CD, Rack Mounting brackets, Smart UPS signalling RS-232 cable, USB cable, User Manual
Specifications
Power
| Output power capacity | 3000 VA |
| Output power | 2700 W |
| Input operation voltage (min) | 140 V |
| Input operation voltage (max) | 280 V |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Power supply input frequency | 50/60 Hz |
| Surge energy rating | 645 J |
| Efficiency | 98.5 % |
| Emergency Power Off (EPO) | |
| Crest factor | 3:1 |
| Output frequency regulation | 50/60 Hz |
Ports & interfaces
| AC outlet types | C13 coupler, C19 coupler |
| Cable length | 1.83 m |
| AC outlets quantity | 10 AC outlet(s) |
| Number of output IEC jumpers | 2 |
| SmartSlot |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Typical backup time at half load | 18 min |
| Typical backup time at full load | 6.3 min |
| Replacement battery cartridge | SMX2200HVNC |
| Battery capacity | 738 VAh |
| Battery life (max) | 5 year(s) |
| Automatic battery test | |
| Hot-swap battery |
Design
| Form factor | Rackmount/Tower |
| Rack capacity | 4U |
| Product colour | Black, Stainless steel |
| Display | LCD |
Performance
| UPS topology | Line-Interactive |
| Hold time (min) | 2 ms |
| Hold time (max) | 10 ms |
| Surge protection | |
| Automatic Voltage Regulation (AVR) | |
| Auto-restart | |
| Waveform | Sine |
| Noise level | 55 dB |
| LED indicators | Status |
| Audible alarm(s) |
Technical details
| Input connections | IEC-320 C20, Schuko CEE 7 / EU1-16P, BS1363A |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
Certificates
| Certification | C-tick, CE, CSA, EN 50091-1, EN 50091-2, EN 60950, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE, REACH |
| RoHS compliance |
Weight & dimensions
| Width | 178 mm (6.94 ") |
| Depth | 483 mm (18.84 ") |
| Height | 432 mm (16.85 ") |
| Weight | 38640 g (85.19 lbs) |
| Package width | 586 mm |
| Package depth | 633 mm |
| Package height | 330 mm |
| Package weight | 47730 g |
Packaging content
| Quick installation guide | |
| Cables included | RS-232, USB cable |
| Manual | |
| Software CD | |
| Rack mount kit |
Logistics data
| Quantity per pallet | 6 pc(s) |
Other features
| Nominal output voltage | 230 V |
