Atdec AD-WF-10090 TV mount
Eligible for Free Shipping & Free Returns
MPN
AD-WF-10090
UPC
881493019737
About this item
<100 kg, VESA 100x200 - 900x600
Fixed-angle wall mount, max. 220lb (100kg). For mounting large heavy displays.
Mounts large and heavy displays parallel to the wall, with multiple features to make installation easy and confident. This mount is for universal application in commercial, domestic, and light industrial environments.
AD-WF-10090 supports displays to 220lb (100kg) with universal VESA 100x200 to 900x600.
The large display will mount with a low profile to wall of just 1.3” (32mm). Installers can use integrated lateral shift capability to position the display precisely as desired. Other installation optimizations include spring-loaded locking tabs for quick display attachment, forgiving slotted mounting holes, and magnetic tipped display release cords (concealable). AD-WF-10090 suits most wall types (with appropriate hardware*).
Mounts large and heavy displays parallel to the wall, with multiple features to make installation easy and confident. This mount is for universal application in commercial, domestic, and light industrial environments.
AD-WF-10090 supports displays to 220lb (100kg) with universal VESA 100x200 to 900x600.
The large display will mount with a low profile to wall of just 1.3” (32mm). Installers can use integrated lateral shift capability to position the display precisely as desired. Other installation optimizations include spring-loaded locking tabs for quick display attachment, forgiving slotted mounting holes, and magnetic tipped display release cords (concealable). AD-WF-10090 suits most wall types (with appropriate hardware*).
Specifications
Mounting
| Maximum weight capacity | 100 kg |
| Minimum VESA mount | 100 x 200 mm |
| Maximum VESA mount | 900 x 600 mm |
| VESA mounting interfaces | 100 x 200,200 x 200,200 x 300,200 x 400,200 x 600,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,400 x 600,600 x 200,600 x 400,800 x 200,800 x 400,800 x 600,900 x 600 mm |
Ergonomics
| Distance to the wall (max) | 32 mm |
| Distance to the wall (min) | 32 mm |
Design
| Product colour | Black |
| Housing material | Steel |
Weight & dimensions
| Width | 1003 mm (39.12 ") |
| Height | 630 mm (24.57 ") |
Logistics data
| Master carton width | 431.8 mm |
| Master carton length | 1130.3 mm |
| Master carton height | 180.34 mm |
| Master carton weight | 24947 g |
| Quantity per master carton | 4 pc(s) |
Packaging data
| Package width | 416.56 mm |
| Package depth | 1115.06 mm |
| Package height | 40.64 mm |
| Package weight | 5307 g |
Other features
| Mounting type | Wall |
| 2 | |
| Y | |
| 20 | |
| Y | |
| Y |
