Aten CS1764A KVM switch
Eligible for Free Shipping & Free Returns
MPN
CS1764A
UPC
672792001987
About this item
4-Port USB DVI KVM Switch with Audio & USB 2.0 Hub (KVM Cables included)
Features
- One USB console controls four DVI computers and two additional USB 2.0 devices- 2-port USB 2.0 hub built in
- Fully compliant with the USB 2.0 specification
- Computer selection via front panel pushbuttons and hotkeys
- Audio enabled
- full bass response provides a rich experience for 2.1 channel surround sound systems
- Multiplatform support
- Windows, Linux, Mac and Sun
- Superior video quality
- 1920 x 1200, 60Hz; DDC2B
- Independent switching of KVM, USB, and Audio focus
- DVI digital and analog monitor support
- fully compliant with the DVI specifications
- HDCP compliant
- Video DynaSync™
- stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
- Power on detection
- if one computer is powered off, the CS1764A will automatically switch to the next powered-on computer
- Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
- Sun /Mac keyboard support and emulation*
- Auto Scan Mode for monitoring all computers
- Firmware upgradable via USB
* 1. PC keyboard combinations emulate Sun/Mac keyboards
* 2. Sun/Mac keyboards only work with their own computers
Package Contents
- 1x CS1764A USB 2.0 DVI KVMP™ Switch- 4x 2L-7D02U USB DVI-D Single Link KVM Cables
- 1x 0AD6-1605-24EG Power Adapter
- 1x User Instructions
Specifications
Video
| Maximum resolution | 1920 x 1200 pixels |
Ports & interfaces
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| Headphone outputs | 4 |
| Number of microphone inputs | 4 |
| DC-in jack |
Design
| Product colour | Black |
Display
| Built-in display |
Power
| Power consumption (typical) | 10.7 W |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Width | 87 mm (3.39 ") |
| Depth | 270 mm (10.53 ") |
| Height | 55 mm (2.15 ") |
| Weight | 940 g (2.07 lbs) |
Other features
| Connectivity technology | Wired |
| Dimensions (WxDxH) | 87 x 270 x 55 mm |
| Ports quantity | 4 |
| Power requirements | DC5.3V |
