Cambium Networks cnMatrix TX 2020R-P Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U
Eligible for Free Shipping & Free Returns
MPN
MXTX2020GXPA10
About this item
cnMatrix TX 2020R-P - Intelligent Ethernet PoE Switch, Cambium Sync, 16 x 1 Gbps and 4 SFP+, Removable & Redundant Power Supplies (not included) - no pwr cord
cnMatrix TX provides Wireless ISP operators a non-blocking, fully managed, enterprise grade L2/L3 switch portfolio, flexible and intelligent PoE and Cambium synchronization in a single box solution that is easy to install and manage while improving network performance.
Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.
Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.
Specifications
Management features
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | |
| Reset button |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
Networking
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x |
| IGMP proxy | |
| Broadcast storm control | |
| Port mirroring | |
| Flow control support | |
| Link aggregation | |
| IGMP entries | 256 |
| 10G support |
Data transmission
| Throughput | 112 Gbit/s |
| Forwarding rate | 120 Mpps |
| MAC address table | 16000 entries |
| Static route | |
| Number of static routes | 64 |
| Jumbo frames support | |
| Jumbo frames | 9000 |
Virtual LAN features
| VLAN support | |
| Number of VLANs | 4000 |
Multicast features
| Multicast support |
Security
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping |
| SSH/SSL support | |
| Access Control List (ACL) | |
| IGMP snooping | |
| MAC address filtering |
Protocols
| Management protocols | SNMP v1/v2/v3 |
Design
| Rack mounting | |
| Form factor | 1U |
Performance
| Processor frequency | 800 MHz |
| Flash memory | 128 MB |
| Internal memory | 512 MB |
| Mean time between failures (MTBF) | 250744 h |
Power
| Power supply included |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
Operational conditions
| Operating temperature (T-T) | -10 - 65 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 55 - 95 % |
Weight & dimensions
| Width | 440 mm (17.16 ") |
| Depth | 350 mm (13.65 ") |
| Height | 44 mm (1.72 ") |
| Weight | 4300 g (9.48 lbs) |
Packaging data
| Package width | 551 mm |
| Package depth | 485 mm |
| Package height | 128 mm |
| Package weight | 5350 g |
Other features
| Y |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
MXTX2020GXPA10 by Cambium Networks
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
