Netgear GS110TP Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Grey Power over Ethernet (PoE)

In stock
SKU
9_GS110TP-300NAS_1
$209.99
Eligible for Free Shipping & Free Returns
MPN
GS110TP-300NAS
UPC
606449137637
About this item
GS110TP 8-Port Gigabit PoE+ Ethernet Smart Managed Pro Switch with 2 SFP Ports and Cloud Management
The NETGEAR GS110TPv3 8-Port Gigabit PoE+ Ethernet Smart Managed Pro Switch comes with 8 PoE copper ports and 2 dedicated SFP ports for fiber uplinks. Cautious spender organizations can now deploy PoE devices with a reasonable PoE power budget of 55W. Each PoE port can provide up to 30 watts to power up the connected devices. Fanless, the GS110TPv3 supports perfectly silent desktop operation or wall mounting. The GS110TPv3 Smart Managed Pro Switch offers an easy-to-use, Web browser-based management GUI with configurable L2 network features like VLANs and PoE operation scheduling, allowing SMB customers to deploy PoE-based VoIP phones and IP surveillance. This switch also comes with NETGEAR Insight Cloud management activation (free for the first two devices) for anytime remote management and monitoring through an intuitive app or Cloud Portal. Advanced features such as IPv4 Layer 2+ static routing including IPv6 management, ACL, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks. The GS110TPv3 features Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings and is backed by NETGEAR’s Lifetime Limited Warranty and 24/7 support including lifetime chat.
Specifications
Management features
Switch type Managed
Switch layer L2/L3/L4
Quality of Service (QoS) support
Web-based management
ARP inspection
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP module slots quantity 2
Copper ethernet cabling technology 10BASE-T,100BASE-TX,1000BASE-T
Networking
Networking standards IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex
Link aggregation
Spanning tree protocol
Broadcast storm control
MAC address auto-aging supported
Flow control support
Port mirroring
Rate limiting
Data transmission
MAC address table 8000 entries
Store-and-forward
Jumbo frames support
Virtual LAN features
Number of VLANs 64
Multicast features
Multicast support
IPv4 multicast entries 32
Number of multicast groups filtered 256
IPv4 & IPv6 features
Access Control List (ACL) IPv6 entries 100
Security
Security algorithms 802.1x RADIUS
IGMP snooping
Access Control List (ACL)
MAC address filtering
Protocols
Data link protocols Ethernet, Fast Ethernet, Gigabit Ethernet
Design
Product colour Grey
LED indicators Activity, Link, PoE, Power, Speed
Performance
Processor frequency 500 MHz
Packet buffer memory 0.5 MB
Flash memory 32 MB
Memory type RAM
Internal memory 128 MB
Mean time between failures (MTBF) 1200041 h
Power
Power consumption (max) 15.1 W
Power supply included
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
DC input voltage 54 V
Input current 1.25 A
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity 8
Power over Ethernet (PoE) power per port 55 W
Total Power over Ethernet (PoE) budget 69.5 W
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 0 - 95 %
Storage relative humidity (H-H) 0 - 95 %
Operating altitude 0 - 3000 m
Non-operating altitude 0 - 3000 m
Heat dissipation 237.38 BTU/h
Weight & dimensions
Width 236 mm (9.2 ")
Depth 101 mm (3.94 ")
Height 27 mm (1.05 ")
Weight 610 g (1.34 lbs)
Packaging data
Package type Box
Package width 161 mm
Package depth 267 mm
Package height 86 mm
Package weight 1230 g
Packaging content
Manual
Logistics data
Master carton width 274 mm
Master carton length 350 mm
Master carton height 309 mm
Master carton weight 8140 g
Quantity per master carton 6 pc(s)
Other features
DHCP client
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for GS110TP-300NAS by Netgear you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
