Siig CN-WR0811-S2 Internal WLAN 300Mbit/s networking card
Free 30 Days Returns
MPN
CN-WR0811-S2
UPC
662774040301
About this item
RT5392, PCI Express, 32-bit, 802.11b/g/n, 2.400 - 2.484GHz, 77.98 x 119.89 x 20.07 mm, 81.65g
SIIG’s DP Wireless-N PCI Express Wi-Fi Adapter with dual profile adds high speed wireless network connectivity to any PCI Express enabled PC. This PCI Express wireless card provides reliable data transfer rate up to 300Mb/s, and is easy to install. Stream media, download files, play games and talk online when connected to a Wireless-N router.
- Complies with 2.4GHz IEEE 802.11 b/g/n standards
- 2T2R with up to 300Mb/s data rate for both transmitting and receiving
- Wireless security: 64/128bit WEP, WPA, WPA2
- Installs in standard height or low profile chassis with included brackets
- Complies with 2.4GHz IEEE 802.11 b/g/n standards
- 2T2R with up to 300Mb/s data rate for both transmitting and receiving
- Wireless security: 64/128bit WEP, WPA, WPA2
- Installs in standard height or low profile chassis with included brackets
- Complies with 2.4GHz IEEE 802.11 b/g/n standards
- 2T2R with up to 300Mb/s data rate for both transmitting and receiving
- Wireless security: 64/128bit WEP, WPA, WPA2
- Installs in standard height or low profile chassis with included brackets
- Complies with 2.4GHz IEEE 802.11 b/g/n standards
- 2T2R with up to 300Mb/s data rate for both transmitting and receiving
- Wireless security: 64/128bit WEP, WPA, WPA2
- Installs in standard height or low profile chassis with included brackets
Specifications
Ports & interfaces
| Connectivity technology | Wireless |
| Internal | |
| Host interface | PCI-E |
| Interface | WLAN |
Bandwidth
| Data transfer rate (max) | 300 Mbit/s |
Wireless LAN features
| Wi-Fi | |
| Top Wi-Fi standard | IEEE 802.11n |
| Wi-Fi standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Bandwidth (second) | 40 GHz |
| Wi-Fi band | Single-band (2.4 GHz) |
| WLAN data transfer rates supported | 300 Mbit/s |
| Bandwidth (first) | 20 GHz |
Networking
| Chipset | RT5392 |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency band | 2.4 - 2.484 GHz |
Antenna
| Antenna | Y |
| Antenna type | External |
| Antenna connector type | RP-SMA |
| Antennas quantity | 2 |
| Detachable antenna(s) | |
| Quality of Service (QoS) support | |
| Gain | 5 dBi |
Protocols
| Media access protocol | CSMA / CA |
Design
| LED indicators | Y |
| Country of origin | China |
Performance
| Security algorithms | 64-bit WEP,128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2 |
Weight & dimensions
| Width | 77.98 mm (3.04 ") |
| Depth | 119.89 mm (4.68 ") |
| Height | 20.07 mm (0.78 ") |
| Weight | 81.65 g (0.18 lbs) |
Certificates
| Certification | FCC, CE |
| RoHS compliance |
Operational conditions
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
Packaging content
| Quantity | 1 |
| Mounting brackets included | |
| Drivers included | |
| Low-profile bracket | |
| Manual | |
| Package type | Box |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
CN-WR0811-S2 by SIIG
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
