Trendnet TEG-25GECTX networking card Ethernet 2500 Mbit/s Internal
Free 30 Days Returns
MPN
TEG-25GECTX
UPC
710931140576
About this item
2.5 Gbit/s, RJ-45, 1.8W, 84x64x18mm, 42g
2.5GBASE-T PCIe Network Adapter
TRENDnet’s 2.5GBASE-T PCIe Network Adapter, model TEG-25GECTX, converts a free PCI Express slot into a 2.5GBASE-T Ethernet port. The 2.5G ethernet adapter includes advanced features such as jumbo frame and VLAN tagging support. Compatible with Windows and Linux desktop computer designs, the 2.5G ethernet adapter includes both standard and low-profile brackets.
2.5G Port
2.5G ethernet adapter supports three speeds: 2.5Gbps, 1Gbps, and 100Mbps.
Jumbo Frame
Sends larger packets, or jumbo frames (up to 9KB), for increased performance.
Operating Systems
Compatible with Windows, Windows Server, and Linux operating systems.
2.5G Port
2.5G ethernet adapter supports three speeds: 2.5Gbps, 1Gbps, and 100Mbps.
PCI Express
Converts a PCIe 2.0 x1 slot into a 2.5G Ethernet Port
2.5GBASE-T Support
2.5GBASE-T specification (802.3bz) supports 2.5G speeds over standard Cat5e cables at distances up to 100m (328 ft.)
Jumbo Frame
Sends larger packets, or jumbo frames (up to 9KB), for increased performance
VLAN Support
2.5G ethernet adapter with IEEE 802.1Q tagged-based VLAN support
Brackets
Supports most installations with included standard and low-profile brackets
Operating Systems
Compatible with Windows, Windows Server, and Linux operating systems
LED Indicators
LED indicators convey port status, link speed and activity
Specifications
Ports & interfaces
| Connectivity technology | Wired |
| Internal | |
| Host interface | PCI Express |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
Bandwidth
| Data transfer rate (max) | 2500 Mbit/s |
Networking
| Ethernet LAN | |
| Networking standards | IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u |
Power
| Power consumption (typical) | 1.8 W |
Design
| Product colour | Blue, Silver |
| LED indicators | Y |
System requirements
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
| Linux operating systems supported | Y |
| Server operating systems supported | Windows Server 2012, Windows Server 2016 |
Weight & dimensions
| Width | 84 mm (3.28 ") |
| Depth | 64 mm (2.5 ") |
| Height | 18 mm (0.7 ") |
| Weight | 42 g (0.09 lbs) |
Certificates
| Certification | CE, FCC |
Operational conditions
| Maximum operating temperature | 40 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
Packaging content
| Quick start guide |
