Tripp Lite SR42UB1032 Freestanding rack 1360.8kg Black rack

Out of stock
SKU
14_SR42UB1032_1
$1,666.00
MPN
SR42UB1032
UPC
037332175359

About this item
42U SmartRack Premium Enclosure, Black
The SR42UB1032 houses 3000 lb of standard 19-inch rack equipment in 42U. Its front and rear pairs of vertical rails have threaded 10-32 mounting holes that are adjustable in quarter-inch increments from 4 to 37 inches. Adjustment is quick and an easy-view depth index ensures consistent rail placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference.

The SR42UB1032 features a massive front-to rear-ventilation capacity that meets or exceeds server manufacturer requirements. Its integrated baying tabs make it easy to combine multiple enclosures in rows for data center applications. This enclosure is also compatible with hot-aisle/cold-aisle configurations.

With its locking, reversible, removable front and rear doors, and locking, removable side panels, the SR42UB1032 provides ultimate equipment safety. The side panels are half size for ease of removal and reinstallation. The split rear door design allows the enclosure to be placed closer to a wall. The SR42UB1032 meets all requirements toward PCI DSS compliance.

The top panel of the SR42UB1032 is vented to help remove warm air from the enclosure and draw in cool air by convection. The top panel includes ports for cable routing, and can be quickly removed without tools. To facilitate cable access, the SR42UB1032 is open-bottom.

All components of the SR42UB1032 are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to the facility earth ground. The removable front and rear doors feature quick-release ground wires.

To simplify deployment, the SR42UB1032 comes with preinstalled casters that enable it to be easily maneuvered into the desired location, where it can be secured by adjusting the preinstalled levelers. Note: the casters are intended for minor position adjustments and are not designed for moving the enclosure over long distances.
Specifications
Features
Type Freestanding rack
Maximum weight capacity 1360.8 kg
Form factor 42U
Product colour Black
Certification EIA-310-E, UL60950, RoHS, UL60950, RoHS
Weight & dimensions
Width 600 mm (23.4 ")
Depth 1092 mm (42.59 ")
Height 1994 mm (77.77 ")
Weight 130000 g (286.6 lbs)
Package weight 151200 g
Other features
Package dimensions (WxDxH) 660.4 x 1143 x 2159 mm
