NETGEAR AX1800 White Power over Ethernet

SKU

68_WAX610PA-100NAS_1

Be the first to review this product

$120.00

Visit our Netgear Store

MPN

WAX610PA-100NAS

UPC

606449151152

Instant WiFi Mesh

nForming wireless backhaul with other WAX6610, WAX610Y, WAC540, or WC564 units to set up a mesh network

Monitor From Anywhere

nUser-friendly remote cloud management with the Insight app

Flexible Mounting

nWall and ceiling kit included

Powerful Business WiFi

nFaster and more reliable WiFi due to higher throughput and more coverage with the use of both 2.4Ghz and 5Ghz bands simultaneously.

Ideal for High Density Environments

nUltimate WiFi performance for schools, hotels, restaurants, and conference centers.

Easy Wiring

nExtra Wired 2.5Gbps Ethernet port that’s backward compatible with 100/1000Mbps Ethernet for easy wiring. WAX610PA version includes power adaptor for non-PoE installations.

Greater Network Capacity

nEnjoy 4x more connection capacity than your current WiFi and improved efficiency for longer battery life.

Seamless, Mesh WiFi

nWire-free installation with other WAX610, WAX610Y, WAC540, or WAC564 creates the perfect seamless business network.

Easy DIY Set Up

nSetup, configure, and manage with the Insight app.

Flexible Mounting

nEasy to securely install on the wall or a suspended ceiling with included hardware.

8 Wireless Networks (SSIDS)

nSeparate and secure networks for admin, guests, employees and IoT like cameras, locks and more.

Separate VLANs

nKeep admin, employees, visitors, HR departments safely separated and segregated.

Peer-to-peer Separation

nPrevent guests from accessing other guests devices on same VLAN

Specifications

Performance

Ethernet LAN data rates	100,1000 Mbit/s
2.4 GHz
5 GHz
Number of users	250 user(s)
MIMO
Remote Authentication Dial-In User Service (RADIUS)
Networking standards	IEEE 802.11ax, IEEE 802.3af
Auto Wireless Distribution System (WDS)
VLAN support

Ports & interfaces

Ethernet LAN (RJ-45) ports	1
DC-in jack

Security

Security algorithms	WPA, WPA2, WPA3
MAC address filtering

Antenna

Antenna type	Internal
Antenna gain level (max)	4.5 dBi

Power

Power consumption (typical)	15.3 W
Input current	2.5 A
Power over Ethernet (PoE)

Design

Placement	Ceiling, Wall
Product colour	White
LED indicators	Power, Status

Features

Maximum data transfer rate (2.4 GHz)	600 Mbit/s
Maximum data transfer rate (5 GHz)	1200 Mbit/s

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Weight & dimensions

Width	160.9 mm (6.28 ")
Depth	160.9 mm (6.28 ")
Height	33.25 mm (1.3 ")
Weight	412 g (0.91 lbs)

Packaging content

Mounting kit

Other features
