Zyxel GS2220-28-EU0101F network switch Managed L2 Gigabit Ethernet (10/100/1000)

SKU

9_GS2220-28_1

Be the first to review this product

$437.00

Visit our ZyXEL Store

MPN

GS2220-28-EU0101F

UPC

760559126759

Powerful L2 features

The GS2220 Series has a rich Layer 2 feature set that can shape the traffic for diverse VoIP, video conference and IPTV deployments. Advanced traffic control features of the GS2220 Series such as L2 multicast, IGMP snooping, Multicast VLAN Registration (MVR) provide hotels, businesses, and educational institutions greater agility and more effective traffic management for the converged applications of today.

Manage it your way!

The support of Zyxel NebulaFlex Pro allows you to easily switch standalone management and intuitive Nebula cloud management platform with 1-YEAR Pro Pack bundled anytime with just a few simple clicks.

Power your devices with efficiency and energy-saving

The PoE models support 802.3at to offer 30W per port along with maximum 375W high-power budget to meet the needs from power-hungry devices. The intelligent consumption mode allows delivery of only the actual power required by devices connected to the switch for better business ROI.

Experience whisper-silent operations

This Series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating.

Flexible port combination

The GS2220 Series includes copper ports and combo ports, 50 and 50HP models even come with additional dedicated SFP ports for uplinks. This flexible port combination can fit in every Layer 2 switching applications easily.

Specifications

Management features

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support
System event log
Web-based management
Configuring Location Settings (CLI)

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	4
Copper ethernet cabling technology	10BASE-TX,1000BASE-T

Networking

Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Flow control support
Spanning tree protocol
Link aggregation
10G support
Rate limiting
Broadcast storm control
Virtual LAN features	Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN

Data transmission

Switching capacity	56 Gbit/s
Forwarding rate	42 Mpps
MAC address table	16000 entries

Virtual LAN features

VLAN support

Multicast features

Multicast support

Security

DHCP features	DHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay
MAC address filtering
Authentication	Guest VLAN, MAC-based authentication
Authentication type	IEEE 802.1x, RADIUS
IGMP snooping
Access Control List (ACL)
Security algorithms	SNMP, SNMPv2, SNMPv3, SSH-2, SSL/TLS

Design

Rack mounting
Product colour	Black
Certification	LVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A

Performance

Flash memory	32 MB
Firmware upgradeable
Internal memory	256 MB
Packet buffer memory	1.5 MB
Mean time between failures (MTBF)	989157 h

Power

Power consumption (max)	22.5 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz

Power over Ethernet (PoE)

Operational conditions

Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 95 %
Storage relative humidity (H-H)	10 - 95 %
Heat dissipation	76.725 BTU/h

Weight & dimensions

Width	441 mm (17.2 ")
Depth	131 mm (5.11 ")
Height	44 mm (1.72 ")
Weight	2200 g (4.85 lbs)

Packaging data

Package width	558 mm
Package depth	214 mm
Package height	79 mm
Package weight	2910 g

Packaging content

Cables included

Other features
