Hanwha XNB-6005 security camera IP security camera Indoor & outdoor Bullet Ceiling/Wall 1920 x 1080 pixels
About this item
2MP, 60fps, CMOS, Dual SD, RJ-45, 73.1 x 66.6 x 147.8 mm, 420 g, Black
2MP, 60fps, CMOS, Dual SD, RJ-45, 73.1 x 66.6 x 147.8 mm, 420 g, Black
Specifications
Performance
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| PTZ control (Pan/Tilt/Zoom) | |
| PTZ modes | Digital PTZ, Preset point |
| Wide Dynamic Range (WDR) | |
| Alarm input/output | |
| Number of languages | 17 |
| Languages support | CHI (SIMPL), CZE, DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR |
Design
| Form factor | Bullet |
| Product colour | Black, White |
| Mounting type | Ceiling/Wall |
| Housing material | Plastic |
| LED indicators | Y |
Video
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2.17 MP |
| Video formats supported | AVC, H.264, H.265, MPEG4 |
| Supported graphics resolutions | 320 x 240,640 x 360,640 x 480 (VGA),720 x 480,720 x 576,800 x 448,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080) |
| Frame rate | 60 fps |
| Video streaming | |
| Flip & mirror |
Camera
| Minimum illumination | 0.0006 lx |
| White balance | ATW, AWC, Indoor, Manual, Mercury lamp, Outdoor, Sodium lamp |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/12000 s |
Image sensor
| Progressive scan | |
| Number of effective pixels (H x V) | 1.945 x 1.097 pixels |
| Sensor type | CMOS |
| Optical sensor size | 1/2 " |
Lens system
| Zoom capability |
Security
| IP address filtering | |
| Motion sensor | |
| HTTPS encryption |
Storage
| Card reader integrated | |
| Compatible memory cards | SD, SDHC, SDXC |
| Maximum memory card size | 512 GB |
Night vision
| Night vision |
Networking
| Ethernet LAN | |
| Ethernet interface type | 10 Gigabit Ethernet,100 Gigabit Ethernet |
| Wi-Fi | |
| Bluetooth | |
| Supported network protocols | TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Streaming method | Multicast, Unicast |
| Number of users | 20 user(s) |
Ports & interfaces
| Connectivity technology | Wired |
| RS-485 ports | 1 |
| USB port | |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-422 ports | 1 |
Audio
| Audio input channels | 1 |
| Audio output channels | 1 channels |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Audio formats supported | G.711 μ-law, G.726 |
| Audio detection |
Weight & dimensions
| Width | 73.1 mm (2.85 ") |
| Depth | 147.8 mm (5.76 ") |
| Height | 66.6 mm (2.6 ") |
| Weight | 420 g (0.93 lbs) |
| Package type | Box |
Power
| Power source type | AC, DC |
| AC input voltage | 24 V |
| Power consumption (Power over Ethernet (PoE)) | 8.5 W |
| Power consumption (max) | 9 W |
| DC output voltage | 12 |
Management features
| Web browser | |
| Reset button | |
| Remotely operated |
Certificates
| Certification | CE. FC |
Operational conditions
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage relative humidity (H-H) | 0 - 90 % |
System requirements
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
Packaging content
| Number of cameras | 1 |
