be quiet! SILENT WINGS 4 | 140mm PWM Computer case Fan 14 cm 1 pc(s)
MPN
BL096
About this item
Silent Wings 4 140mm PWM, 1100RPM, 13.6dB, FDB, 51.3cfm, 87.16m3/h
No compromise silence and performance
Silent Wings 4 140mm PWM combines all features of a virtually inaudible with an extremely performant fan. A 6-pol-motor and anti-vibration mountings combined with fan blades optimized for maximum airflow make Silent Wings 4 140mm PWM the perfect choice for the most demanding applications in high-end systems. Specifications
Performance
| Type | Fan |
| Fan diameter | 140 mm |
| Rotational speed (max) | 1100 RPM |
| Noise level (high speed) | 13.6 dB |
| Maximum airflow | 51.3 cfm |
| Maximum air pressure | 0.92 mmH2O |
| Airflow | 87.16 m³/h |
| Pulse-width modulation (PWM) support | |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Fan connector | 4-pin |
| Mean time between failures (MTBF) | 300000 h |
Design
| Product colour | Black |
| Cable length | 0.5 m |
| Certification | CE / ROHS / RU / UKCA / TÜV / WEEE |
Power
| Power consumption (typical) | 3.6 W |
| Voltage | 5 - 13.2 V |
| Rated voltage | 12 V |
| Rated current | 0.3 A |
| Maximum current | 0.33 A |
Weight & dimensions
| Width | 140 mm (5.46 ") |
| Depth | 140 mm (5.46 ") |
| Height | 25 mm (0.98 ") |
| Weight | 220 g (0.49 lbs) |
| Package width | 156 mm |
| Package depth | 206.5 mm |
| Package height | 31 mm |
| Package weight | 387 g |
Packaging content
| Number of screws | 4 |
| Screws included |
Other features
| Country of origin | China |
| 13580 | |
| 4 | |
| 1 | |
| Computer case | |
| 317 | |
| 463 | |
| 388 | |
| 32 |
