Tripp Lite 1.8kW Single-Phase Basic PDU, 120V Outlets (13 5-15R), 5-15P, 15ft Cord, 1U Rack-Mount

MPN
PDU1215
UPC
037332116727

About this item
1.8kW Single-Phase Basic PDU, 120V Outlets (13 5-15R), 5-15P, 15ft Cord, 1U Rack-Mount
Tripp Lite's PDU1215 1.8kW 15A Single-Phase Basic Power Distribution Unit (PDU) is a dependable, space-saving, cost-effective way to deliver 120V power to wiring closets, server rooms and equipment racks from a UPS system, generator or utility wall outlet in high-density IT environments. With 13 NEMA 5-15R outlets (1 front, 12 rear), a rugged all-metal housing and a switchless design to prevent accidental shutoff, the PDU1215 is a basic power distribution unit for networking, PC systems, telecommunications, audio/video, security, sound reinforcement, and other similar applications. The PDU1215 includes hardware for 1U rackmount installation. Other mounting configurations include vertical 0U rackmount (with compatible racks and PDUSIDEBRKT accessory, sold separately), wall-mount, workbench and under-counter installations.
- 1.8kW 15A 120V single phase Basic Power Distribution Unit / PDU
- 1U horizontal 19 inch rackmount form factor installs in one rack space
- NEMA 5-15P 15A 120v input plug with 15 ft. / 4.5m line cord
- 13 NEMA 5-15R outlets (1 front / 12 rear)
- Adjustable mounting brackets enable installation in 2 or 4 post racks, plus additional support for wallmount and under-counter mounting
- Mounting ears are reversible for front or rear facing rackmount installation
- Optional PDUSIDEBRKT enable 0U vertical installation in compatible racks
- Back-panel grounding lug
- RoHS-compliant
Specifications
Design
PDU types Basic
Rack capacity 1U
Mounting Horizontal
Material Metal
Product colour Black
RoHS compliance
Certification UL60950-1/CSA-C22.2
Ports & interfaces
AC outlets quantity 13 AC outlet(s)
Power plug NEMA 5–15P
AC outlet types NEMA 5–15R
I/O ports 13 x NEMA 5-15R
Ergonomics
Cable length 4.57 m
Operational conditions
Storage temperature (T-T) -15 - 50 °C
Operating altitude 0 - 3000 m
Power
Nominal input voltage 100-127 V
Maximum current 15 A
Nominal output voltage 100-127 V
Weight & dimensions
Dimensions (WxDxH) 445 x 114 x 44.4 mm
Weight 2200 g (4.85 lbs)
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for PDU1215 by Tripp Lite you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
