Tripp Lite 3.3/3.8kW Single-Phase Basic PDU, 208/240V 20A (2 C19, 12 C13), L6-20P, 208/240V Input, 15ft Cord, 1U Rack-Mount

In stock
SKU
6_PDUH20HVL6_1
$181.00
Eligible for Free Shipping & Free Returns
MPN
PDUH20HVL6
UPC
037332158970
About this item
3.3/3.8kW Single-Phase Basic PDU, 208/240V 20A (2 C19, 12 C13), L6-20P, 208/240V Input, 15ft Cord, 1U Rack-Mount
Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution for critical IT equipment in wiring closets, server rooms and equipment racks. Supplies continuous power from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
- 20A single phase 208/240V Basic Power Distribution Unit / PDU (Agency de-rated to 16A continuous)
- Attached NEMA L6-20P input with 15 ft. / 4.5m line cord
- 1U horizontal rackmount format installs in one rack space
- 14 outlets (2 C19, 12 C13)
- Adjustable mounting brackets enable installation in 2 or 4 post racks, plus additional support for wallmount and under-counter mounting
- Mounting ears are reversible for front or rear facing rackmount installation
- Back panel grounding lug
Specifications
Design
PDU types Basic
Rack capacity 1U
Mounting Horizontal
Material Metal
Product colour Black
RoHS compliance
Certification UL 60950 (USA), CSA (Canada)
Ports & interfaces
AC outlets quantity 14 AC outlet(s)
Power plug NEMA L6-20P
AC outlet types C13 coupler, C19 coupler
Ergonomics
LED indicators Y
Cable length 4.5 m
Operational conditions
Storage temperature (T-T) -15 - 50 °C
Operating altitude 0 - 3000 m
Power
Nominal input voltage 200-240 V
AC input frequency 50/60 Hz
Maximum current 20 A
Nominal output voltage 200-240 V
Weight & dimensions
Dimensions (WxDxH) 438 x 95 x 44.5 mm
Weight 1700 g (3.75 lbs)
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for PDUH20HVL6 by Tripp Lite you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
