Ubiquiti Networks US-24 24-Port Unifi Managed Gigabit Switch With SFP
MPN
US-24
UPC
810354024740
About this item
- UniFi Switch brings together Gigabit performance, intelligent switching, and 24 RJ45 Gigabit ports in one highly accessible Gigabit switch;
- UniFi Switches offer the capability of simultaneously processing traffic on all ports at line rate without packet loss;
- With two SFP ports, the model US-24 can be used for uplinks as high as 1Gbps;
- A switching capacity of 52 Gbps, a forwarding rate of 38.69 Mpps;
- 25 Watts maximum power, rack-mountable;
A managed Gigabit switch equipped with SFP ports
and 24 RJ45 Gigabit ports, the UniFi Switch provides the stability and smart switching you need for your growing network.
Enterprise Switch Model That Deliver Power
Using the UniFi Switch, all ports can be forwarded simultaneously at line speed without packet loss.
With its non-blocking throughput, the 24-port model supports up to 26 Gbps.
A multi-site management system
Multi-Site Management can be managed by a single UniFi Controller instance, running in the cloud.
Admin accounts and network monitoring are separate for each site, along with configuration, maps, and statistics.
High-speed optical fiber backhaul
There are two SFP ports supporting uplink speeds up to 1 Gbps.
Non-blocking throughput
Throughput of the 24-port model is 26 Gbps.
Connectivity Capacity
UniFi Switches offer the capability of simultaneously processing traffic on all ports at line rate without packet loss.
Options for versatile mounting
A UniFi switch can be positioned on a desk, wall, or rack.
Integrate seamlessly
Incorporated directly into the UniFi Software-Defined Networking (SDN) platform, the UniFi Switch allows users to manage network devices across multiple sites through a single user interface.
Specifications
Management features
| Switch type | Managed |
| Reset button |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Console port | RJ-45 |
Networking
| Flow control support | |
| Spanning tree protocol | |
| 10G support | |
| Port mirroring |
Data transmission
| Switching capacity | 52 Gbit/s |
Security
| Security algorithms | 802.1x RADIUS |
Design
| Rack mounting | |
| Form factor | 1U |
| Product colour | White |
| LED indicators | Activity, Link, Speed |
| Number of fans | 1 fan(s) |
| Certification | CE, FCC, IC |
Performance
| Noise level | 37 dB |
Power
| Power consumption (max) | 25 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) |
System requirements
| Compatible operating systems | Linux, Mac OS X, or Microsoft Windows 7/8/10 |
Operational conditions
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
Weight & dimensions
| Width | 443 mm (17.28 ") |
| Depth | 221 mm (8.62 ") |
| Height | 43 mm (1.68 ") |
| Weight | 2510 g (5.53 lbs) |
Packaging content
| Quick start guide | |
| Mounting brackets included |
