D-Link DGS-1100-24V2 network switch Managed Gigabit Ethernet (10/100/1000) 1U

In stock
Only 5 left
SKU
9_DGS-1100-24V2_1
$133.00
Eligible for Free Shipping & Free Returns
MPN
DGS-1100-24V2
UPC
790069451775
About this item
24x 10/100/1000BASE-T, 48 Gbps, 35.71 Mpps, VLAN, 280x180x44 mm

Powerful Switching for your Business

The DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.

Easy to Use & Easy to Install

D-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.

VLANs: Stronger Security & Better Traffic Management

Relatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.

For Voice

If VoIP calls make up a large slice of your network usage, separating them onto their own VLAN can ensure they get the bandwidth they need for smooth conversations without lag or jitters.

For Surveillance

If you have surveillance cameras and devices attached to your network, putting them onto their own VLAN keeps surveillance footage running seamlessly. At the same time, it can help prevent a variety of malicious attacks by restricting access to different network areas.

Green Technology

D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.
Specifications
Management features
Switch type Managed
System event log
Web-based management
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Networking
Networking standards IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x
Head-of-line (HOL) blocking
Port mirroring
Link aggregation
Flow control support
Spanning tree protocol
Broadcast storm control
Auto MDI/MDI-X
IGMP entries 64
Rate limiting
Virtual LAN features Port-based VLAN, Voice VLAN
Data transmission
Switching capacity 48 Gbit/s
Forwarding rate 35.71 Mpps
MAC address table 8000 entries
Store-and-forward
Number of queues 4
Jumbo frames support
Jumbo frames 9216
Virtual LAN features
VLAN support
Number of VLANs 4094
Multicast features
Multicast support
Security
DHCP features DHCP client
Security algorithms SNMP, SSL/TLS
Queue scheduling algorithms SPQ, Weighted Round Robin (WRR)
IGMP snooping
Design
Rack mounting
Form factor 1U
Product colour Black
LED indicators Y
Electromagnetic compatibility FCC A, CE A, VCCI A, C-Tick, BSMI, CCC
Certification RoHS 6 cUL, CE LVD, CB, BSMI, CCC
Performance
Processor frequency 125 MHz
Flash memory 16 MB
Packet buffer memory 4.1 MB
Mean time between failures (MTBF) 424762 h
Power
Power consumption (typical) 4.5 W
Power consumption (max) 15.9 W
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Operational conditions
Operating temperature (T-T) -5 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 0 - 95 %
Storage relative humidity (H-H) 0 - 95 %
Operating altitude 0 - 2000 m
Heat dissipation 54.3 BTU/h
Weight & dimensions
Width 280 mm (10.92 ")
Depth 180 mm (7.02 ")
Height 44 mm (1.72 ")
Weight 1470 g (3.24 lbs)
Packaging content
Rack mount kit
Other features
Y
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for DGS-1100-24V2 by D-Link you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
