Eaton 9PX3000GLRT uninterruptible power supply (UPS) 3 AC outlet(s) Double-conversion (Online)
MPN
9PX3000GLRT
UPC
743172081315
About this item
Double-conversion online, 3000VA, 3000W, 2 x L6-20R & 1 x L6-30R Outlets
Reliable. Versatile. Powerful. Efficient. With double-conversion topology for constant power conditioning and up to 93 percent efficiency, the Eaton 9PX 700-3000 VA models support your overall goal of business continuity. It’s built for scalable deployment, features a graphical LCD for local status updates and integrates with virtualized environments.
Specifications
Power
| Output power | 3000 W |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 276 V |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Power supply input frequency | 50/60 Hz |
| Efficiency | 93 % |
| Emergency Power Off (EPO) | |
| Input power factor | 0.99 |
| Power factor | 1 |
| Output voltage regulation | 1 % |
| Output voltage THD | 3 % |
Ports & interfaces
| AC outlet types | NEMA L6-20R, NEMA L6-30R |
| Power plug | NEMA L6-20P |
| AC outlets quantity | 3 AC outlet(s) |
| USB port | |
| USB 2.0 ports quantity | 1 |
| Serial interface | |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
| Cold start |
Design
| Form factor | Rackmount/Tower |
| Rack capacity | 2U |
| Product colour | Black, Silver |
| Display | LCD |
Performance
| UPS topology | Double-conversion (Online) |
| Surge protection | |
| Noise level | 47 dB |
| LED indicators | Y |
Technical details
| Output connections | 2 x L6-20R & 1 x L6-30R |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 55 °C |
| Operating relative humidity (H-H) | 0 - 96 % |
| Operating altitude | 0 - 3000 m |
Certificates
| RoHS compliance | |
| Energy Star certified | |
| Certification | IEC 62040-2 Class B Cat C2 / CISPR22 Class B / FCC part 15 Class B / VCCI Class B CE / cULus / NOM |
Weight & dimensions
| Width | 440 mm (17.16 ") |
| Depth | 605 mm (23.6 ") |
| Height | 86.5 mm (3.37 ") |
| Weight | 27400 g (60.41 lbs) |
Packaging content
| Cables included | Input power cable, Output power cable, RS-232, USB cable |
| Manual | |
| Quick installation guide |
Other features
| Nominal input voltage | 208 V |
| Nominal output voltage | 208 V |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
9PX3000GLRT by Eaton
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
