Monoprice 24281 AV extender AV transmitter & receiver
MPN
24281
UPC
889028054116
About this item
Blackbird 4K HDMI Extender, 50m - 4K HDMI Extension to 164 feet
This Blackbird™ 4K HDMI® Extender allows you to transmit 4K@30Hz video to distances up to 164 feet (50 meters) or 1080p@60Hz video to distances up to 196 feet (60 meters) over a single Cat6 Ethernet cable. It supports video resolutions up to 4K@30Hz, including 1080p@60Hz, and high-definition multi-channel audio. It supports the Power over Cable (PoC) feature, which allows you to power the receiver or transmitter over the Ethernet cable, and bidirectional, wideband IR extension, so you can control the source and remote display from the opposite locations.
Specifications
Features
| Type | AV transmitter & receiver |
| Cable types supported | Cat6 |
| Maximum transfer distance | 60 m |
| HDCP pass-through | |
| Electrostatic Discharge (ESD) protection | |
| Colour depth | 8 bit |
| Wall mountable | |
| Supported video modes | 1080p |
| Rubber feet | |
| Carrier frequency | 60 kHz |
| Bandwidth | 10.2 Gbit/s |
| LED indicators | Y |
| Control type | Buttons |
| Rack mounting | |
| Exterior material | Plastic |
| On/off switch | |
| HDCP version | 2.2 |
| HDCP | |
| Product colour | Black |
| Integrated antenna | |
| Certification | CE, FCC, UL |
Ports & interfaces
| Connectivity technology | Wired |
| Ethernet LAN | |
| RJ-45 input ports | 1 |
| HDMI in | 1 |
| HDMI version | 1.4 |
| Component video (YPbPr/YCbCr) out | 1 |
| Component video (YPbPr/YCbCr) in | 1 |
| DC-in jack |
Power
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating voltage | 12 V |
| Input current | 1 A |
| Power consumption (transmitter) (max) | 10 W |
| Power consumption (receiver) (max) | 15 W |
Operational conditions
| Operating relative humidity (H-H) | 20 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Width | 88 mm (3.43 ") |
| Depth | 17 mm (0.66 ") |
| Height | 61 mm (2.38 ") |
| Weight | 144 g (0.32 lbs) |
| Receiver dimensions (W x D x H) | 88 x 17 x 61 mm |
| Receiver weight | 144 g |
| Transmitter dimensions (WxDxH) | 88 x 17 x 61 mm |
| Transmitter weight | 144 g |
Packaging content
| AC adapter included | |
| Quick start guide |
