Siig JU-DK0H11-S1 notebook dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-B

SKU

9_JU-DK0H11-S1_1

Be the first to review this product

$170.00

Visit our SIIG Store

MPN

JU-DK0H11-S1

UPC

662774044057

5K/4K Video Resolution

Allows you to connect either a single 5K (5120x2880) @60Hz display through two DisplayPort ports or two 4K (3840x2160) @60Hz Ultra HD displays through two DisplayPort ports or two HDMI ports or a DisplayPort + a HDMI ports to display the cry stal-clear video quality

Three Display Modes

Provides Mirror, Extended, and Primary video modes, streaming video to HDTV monitors and projectors for the perfect visual display

High Performamce

Expand multiple connectivity ports to your USB-A/USB-C computer to increase your efficiency. This Universal Hybrid Dual 4K Video Docking Station is fully certified to meet DisplayLink certification DisplayLink graphics technology works with any computer, connector types and connect multiple displays functionality to increase in work productivity. Compatible with USB-A, USB-C, etc.

Multiple Connectivity Ports

Adds one USB 3.0 Type-B port (includes USB-A to USB-B cable and USB-C to USB-B cable for easy conversion), two HDMI video outport ports, two DisplayPort video output ports, six USB 3.0 Type-A ports, one Gigabit Ethernet, and one 3.5mm audio jack to connect headphone / Stereo speaker or microphone input

SuperSpeed USB Data Transfer

Delivers six USB 3.0 Type-A ports and supports data transfer rate up to 5Gbps

1G Ethernet Data Transmission

Up to 1,000Mbps data transfer rate and seamless backward compatible with 10/100 Mbps Enterprise Features: - Wake on LAN - MAC Address Pass-Through - PXE Boot

Maximum Cpmpatibility

Compatible with Windows 10 / 8.1 / 8 / 7 and mac OS 11 / 10.15 to 10.10 *Note: 1. not compatible with 10.13.4 to 10.13.6 and recommended to upgrade to 10.14 or later or stay with 10.13.3 or earlier 2. Uninstall any legacy DisplayLink driver (v5.2.5 or earlier) and install the latest driver (macOS 10.15.6 or later) on SIIG’s website 3. Does not support movie/video playback via iTunes and HDCP protected content via Safari web browser (Netflix, Amazon Prime, Hulu, HBO Go, etc.)

ABS Housing Design

Vertical design and smooth ABS housing with heat dissipation design for reliable performance, increase efficiency, and save space

Specifications

Ports & interfaces

Connectivity technology	Wired
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-B
USB 3.0 (3.1 Gen 1) Type-A ports quantity	6
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	2
HDMI version	2.0
DisplayPorts quantity	2
DC-in jack
Microphone in
Combo headphone/mic port

Networking

Ethernet LAN
Ethernet LAN data rates	10,100,1000 Mbit/s
Wake-on-LAN ready
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Storage

Card reader integrated

Performance

Full duplex
Housing material	Acrylonitrile butadiene styrene (ABS)

Power

Power source type	AC
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Output current	2 A
Output voltage	20 V

Design

Product colour	Black
Country of origin	Thailand
Certification	FCC, CE, RoHS

Software

Windows operating systems supported	Windows 10
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	10 - 90 %

Weight & dimensions

Width	72.8 mm (2.84 ")
Depth	134.8 mm (5.26 ")
Height	186.9 mm (7.29 ")
Weight	349.2 g (0.77 lbs)

Packaging content

Quantity per pack	1 pc(s)
Cables included	USB Type-A to USB Type-B
User guide
AC adapter included

Other features

	1.2
	CE, RoHS
