Star Micronics Desktop USB 1D/2D Barcode Scanner BSD-FR4080
About this item
- Brand Star Micronics;
- Manufacturer Part Number 37950440;
- Color Multicolor;
- Product Dimensions L x W x H -3.20 x 3.30 x 4.00 Inch;
Star Micronics Desktop USB 1D/2D Barcode Scanner BSD-FR4080, which is equipped with a powerful CPU, can read 1D and high-volume 2D barcodes on any screen, including those with protective film
The scanner's built-in IR sensor allows for quick barcode capture, boosting throughput and productivity.
The top of the scanner
The scanner's IP52-rated architecture protects it against dust, water, and other impurities, making it long-lasting.
The top of the scanner features a button that allows users to easily switch between regular and high-motion-tolerance modes.
The Star Micronics Desktop USB 1D/2D Barcode Scanner BSD-FR4080's high motion tolerance (2.5m/s) and wide field of view (horizontal 51°, vertical 32°) improve the user experience even more. Multiple 1.2m fall to concrete are likewise no problem for the scanner.
Features:
- Quick Switch Mode: Effortlessly toggle between normal and high-motion-tolerance modes;
- Superior Motion Tolerance: 2.5m/s motion tolerance and large field of view (horizontal 51°, vertical 32°);
- On-Screen Capture: Captures barcodes on screens covered with protective film;
- Infrared Sensor: Automatic scanning increases productivity and speed in dark environments or when distance to the barcode changes; IP52-Rated Design: Protected from dust, water, and more;
- CMOS: Quieter and better performance in low light environments; Drop Resistance: Withstands up to 1.2m drops;
- Can Plug Directly into Star’s mCollection Products (mC-Print2/3 & mPOP);
Specifications
Scanning
| Optical sensor resolution (W x H) | 1280 x 800 pixels |
| Scanner type | 1D/2D |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar, ISBN, ISSN, ITF-14, ITF-6, Interleaved 2 of 5, MSI, Matrix 2 of 5, Plessey, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Micro QR Code, PDF417, QR Code |
| Sensor type | CMOS |
| Motion tolerance (cm/s) | 250 |
| Tilt reading angle | -50 - 50 ° |
| Pitch reading angle | -45 - 45 ° |
Ports & interfaces
| Connectivity technology | Wired |
| Standard interfaces | RS-232, USB |
Design
| Type | Barcode module bar barcode readers |
| International Protection (IP) code | IP52 |
| LED indicators | Y |
| Product colour | Black |
| Certification | FCC Part15 Class B, CE EMC Class B |
Performance
| Buzzer |
Power
| Power source type | DC, USB |
| Power consumption (typical) | 1.041 W |
| Input voltage | 5 V |
| Power consumption | 219 mA |
Operational conditions
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Width | 83 mm (3.24 ") |
| Depth | 81 mm (3.16 ") |
| Height | 148 mm (5.77 ") |
| Weight | 293 g (0.65 lbs) |
Packaging content
| External power adapter | |
| Cables included | RS-232, USB |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
37950440 by Star Micronics
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
