Aten VE803 AV transmitter & receiver BK,Grey AV extender
MPN
VE803
UPC
0672792004285
About this item
HDMI USB Extender (Trasmitter & Receiver), 60m max, Cat 5e
The VE803 HDMI USB Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters and 1080p signals up to 40 meters.
The VE803 is equipped with USB connectors which allow you to extend any USB device between the units. The USB feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit.
The VE803 is equipped with USB connectors which allow you to extend any USB device between the units. The USB feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit.
Specifications
Features
| Type | AV transmitter & receiver |
| Cable types supported | Cat5e |
| Maximum transfer distance | 60 m |
| LED indicators | Y |
| Supported video modes | 1080i,1080p |
| Product colour | Black, Grey |
| RoHS compliance |
Ports & interfaces
| RJ-45 input ports | 2 |
| RJ-45 output ports | 2 |
| Number of HDMI outputs | 1 |
| HDMI in | 1 |
| USB ports quantity | 2 |
| DC-in jack |
Power
| Operating voltage | 5 V |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
Weight & dimensions
| Dimensions (WxDxH) | 31.6 x 71.6 x 23 mm |
| Weight | 160 g (0.35 lbs) |
Technical details
| Connector(s) | HDMI Type A, USB Type B, USB Type A, RJ-45 |
