Eaton 9PX3K3UNTF5 uninterruptible power supply (UPS) 3000 VA 21 AC outlet(s) Double-conversion (Online)
MPN
9PX3K3UNTF5
UPC
743172082510
About this item
Double-conversion online, 3000VA, 3000W, 18 x 5-20R & 2 x L6-20R & 1 x L6-30R
Reliable. Versatile. Powerful. Efficient. With double-conversion topology for constant power conditioning and up to 93 percent efficiency, the Eaton 9PX 700-3000 VA models support your overall goal of business continuity. It’s built for scalable deployment, features a graphical LCD for local status updates and integrates with virtualized environments.
Specifications
Power
| Output power capacity | 3000 VA |
| Output power | 3000 W |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 276 V |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 240 V |
| Power supply input frequency | 50/60 Hz |
| Efficiency | 92 % |
| Output voltage THD | 2 % |
| Input power factor | 0.99 |
| Output voltage regulation | 1 % |
| Power factor | 1 |
Ports & interfaces
| AC outlet types | NEMA 5–20R, NEMA L6-20R, NEMA L6-30P |
| AC outlets quantity | 21 AC outlet(s) |
| USB port | |
| USB 2.0 ports quantity | 1 |
| Serial interface | |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
| Hot-swap battery | |
| Cold start |
Design
| Form factor | Rackmount/Tower |
| Rack capacity | 6U |
| Product colour | Black, Silver |
| Display | LCD |
Performance
| UPS topology | Double-conversion (Online) |
| Surge protection | |
| Noise level | 45 dB |
| LED indicators | Y |
Management features
| Web-based management | |
| Management protocols | SNMP |
Technical details
| Output connections | 18 x 5-20R & 2 x L6-20R & 1 x L6-30R |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
Certificates
| RoHS compliance | |
| Energy Star certified | |
| Certification | IEC 62040-2:2006 Cat C2 / CISPR22 Class A / FCC part 15 Class A CE / cULus / NOM |
Weight & dimensions
| Width | 439 mm (17.12 ") |
| Depth | 721 mm (28.12 ") |
| Height | 259 mm (10.1 ") |
| Weight | 91000 g (200.62 lbs) |
Packaging content
| Quick installation guide | |
| Cables included | RS-232, USB cable |
| Manual |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
9PX3K3UNTF5 by Eaton
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
