TP-Link Omada 18-Port Gigabit Smart Switch with 16-Port PoE+
About this item
16× 10/100/1000 Mbps PoE+ RJ45, 2× Gigabit SFP Slots, 36 Gbps, 8K MAC, 9 KB Jumbo, 440 × 180 × 44 mm
TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The
switches can be managed by Omada SDN Controller, which provides professional and reliable one-step
solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing
provide cost-effective networking solutions for small and medium-sized businesses without sacrificing
enhanced usability and strong performance.
switches can be managed by Omada SDN Controller, which provides professional and reliable one-step
solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing
provide cost-effective networking solutions for small and medium-sized businesses without sacrificing
enhanced usability and strong performance.
Specifications
Management features
| Switch type | Managed |
| Switch layer | L2/L2+ |
| Quality of Service (QoS) support | |
| System event log | |
| Cloud-managed | |
| MIB support | MIB II (RFC1213), Bridge MIB (RFC1493), P/Q-Bridge MIB (RFC2674), Radius Accounting Client MIB (RFC2620), Radius Authentication Client MIB (RFC2618), Remote Ping, Traceroute MIB (RFC2925), Support TP-Link private MIBs, RMON MIB(RFC1757, rmon 1,2,3,9) |
| ARP inspection | |
| Configuring Location Settings (CLI) | |
| Web-based management |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
Networking
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Flow control support | |
| Link aggregation | |
| Auto MDI/MDI-X | |
| Broadcast storm control | |
| Policy-based routing | |
| Rate limiting | |
| Spanning tree protocol | |
| IP routing | |
| 10G support |
Data transmission
| Switching capacity | 26.78 Gbit/s |
| Forwarding rate | 26.78 Mpps |
| MAC address table | 8000 entries |
| Jumbo frames support | |
| Jumbo frames | 9 |
Virtual LAN features
| VLAN support |
Multicast features
| Multicast support | |
| Multicast features | Multicast forwarding |
Security
| DHCP features | DHCP client, DHCP relay, DHCP snooping |
| Access Control List (ACL) | |
| Loop protection | |
| SSH/SSL support | |
| BPDU filtering/protection | |
| Static port security | |
| Authentication | MAC-based authentication, Port-based authentication |
| MAC address filtering |
Design
| Rack mounting | |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Y |
| Certification | CE, FCC, RoHS |
Performance
| Packet buffer memory | 4.1 MB |
| Auto-negotiation |
Power
| Power source | DC/PoE |
| Power consumption (max) | 181.4 W |
| AC input voltage | 100 - 240 V |
| Power supply included | |
| AC input frequency | 50/60 Hz |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | |
| Total Power over Ethernet (PoE) budget | 150 W |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Heat dissipation | 619.06 BTU/h |
Weight & dimensions
| Width | 440 mm (17.16 ") |
| Depth | 180 mm (7.02 ") |
| Height | 44 mm (1.72 ") |
Packaging data
| Package type | Box |
Packaging content
| User guide | |
| Cables included | LAN (RJ-45) |
Other features
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
