TP-Link Omada DS111P network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black
MPN
DS111P
UPC
840030712531
About this item
8-Port 10/100Mbps + 3-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE+, 7.6 Gbps, Fanless, 77.32 W
8-Port 10/100Mbps + 3-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE+, 7.6 Gbps, Fanless, 77.32 W
Specifications
Management features
| Switch type | Unmanaged |
| Quality of Service (QoS) support |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 10 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| SFP module slots quantity | 1 |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX |
| Fast Ethernet (copper) ports quantity | 8 |
| Gigabit Ethernet (copper) ports quantity | 2 |
Networking
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3x |
| Auto MDI/MDI-X | |
| Flow control support | |
| 10G support | |
| MAC address auto-learning supported | |
| MAC address auto-aging supported |
Data transmission
| Switching capacity | 7.6 Gbit/s |
| Forwarding rate | 5.6544 Mpps |
| MAC address table | 2000 entries |
| Store-and-forward | |
| Jumbo frames support | |
| Jumbo frames | 16 |
Design
| Product colour | Black |
| LED indicators | Activity, Link, PoE, Power |
| Housing material | Metal |
| Wall mountable |
Performance
| Auto-negotiation | |
| Fanless |
Power
| Power source | DC |
| Power connector | DC-in jack |
| Power consumption (max) | 77.32 W |
| Power supply included | |
| Input current | 1.31 A |
| DC input voltage | 53.5 V |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 65 W |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Heat dissipation | 263.7 BTU/h |
Weight & dimensions
| Width | 209 mm (8.15 ") |
| Depth | 126 mm (4.91 ") |
| Height | 26 mm (1.01 ") |
Packaging content
| Cables included | Power |
| Rubber feet | |
| User guide |
Other features
| Ethernet LAN data rates | 10,100 Mbit/s |
| CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), RoHS, UKCA |
