CyberPower BP36V60ART2U uninterruptible power supply (UPS) 10 AC outlet(s)
Eligible for Free Shipping & Free Returns
MPN
BP36V60ART2U
UPC
649532604951
About this item
Extended Battery Module - 36V / 60A, 6x12V/9AH Sealed lead-acid, 5h, 2U, 22.9kg, Black
The CyberPower BP36V60ART2U (36V) Extended Battery Module (EBM) with DC plug-n-play connections and Fast Charge Technology provide extended battery run-time during power outages for select Smart App Online UPS models. Up to 10 EBMs can be added and fast charging times are maintained thanks to each EBM having a built in battery charger. The typical charging times of 5 hours for the OL1000RTXL2U and OL1500RTXL2U are maintained whether there are 1 or 10 EBMs installed.
Each EBM takes up 2U of rack space and can also be installed in a tower form factor to match the UPS. A DC plug-n-play power connector makes it easy to daisy-chain additional EBMs to a UPS system.
A Three-Year Warranty ensures that this extended battery module has passed our highest quality standards in design, assembly, material or workmanship.
Each EBM takes up 2U of rack space and can also be installed in a tower form factor to match the UPS. A DC plug-n-play power connector makes it easy to daisy-chain additional EBMs to a UPS system.
A Three-Year Warranty ensures that this extended battery module has passed our highest quality standards in design, assembly, material or workmanship.
Specifications
Power
| Output operation voltage (min) | 36 V |
| Maximum current | 60 A |
Ports & interfaces
| AC outlets quantity | 10 AC outlet(s) |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery type | 12V/9AH |
| Number of battery cells | 6 |
| Battery recharge time | 5 h |
| Hot-swap battery |
Design
| Form factor | Rackmount |
| Rack capacity | 2U |
| Product colour | Black |
| Material | Steel |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
Certificates
| RoHS compliance | |
| Certification | UL1778, CSA C22.2 NO.107.3-05, FCC DOC A |
Weight & dimensions
| Width | 433 mm (16.89 ") |
| Depth | 430 mm (16.77 ") |
| Height | 88 mm (3.43 ") |
| Weight | 22900 g (50.49 lbs) |
| Package weight | 29600 g |
Other features
| Package dimensions (WxDxH) | 550 x 590 x 240 mm |
