iPC Store

Tripp Lite TAA SmartPro 120V 1kVA 800W Line-Interactive Sine Wave UPS, 1U, Network Card Options, USB, 6 Outlets

In stock
SKU
9_SM1000RM1UTAA_1
$878.00
Eligible for Free Shipping & Free Returns
MPN
SM1000RM1UTAA
UPC
037332184184
About this item
TAA SmartPro 120V 1kVA 800W Line-Interactive Sine Wave UPS, 1U, Network Card Options, USB, 6 Outlets
Tripp Lite's SM1000RM1UTAA is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases. This intelligent, line-interactive sine wave rack/tower uninterruptible power supply prevents data loss, downtime and equipment damage due to power outages, voltage fluctuations and transient surges. Requires only two rack spaces (1U) in a standard rack enclosure. Large internal batteries offer 17 minutes half load runtime and 7 minutes at full load. Maintains regulated 120V nominal output without using battery power during brownouts and overvoltages from 83 to 147V. 1000VA/700 watt power handling capability and full time sine wave output supports networking, telecom and other sensitive electronic applications. Includes a total of 6 outlets arranged in 2 load banks that are individually controllable via software interface to reboot select equipment on demand or shed less significant loads to extend battery runtime for more critical equipment. Supports simultaneous remote monitoring of UPS and site power conditions via built-in network accessory card slot, USB and DB9 serial monitoring ports. Optional SNMPWEBCARD accessory enables remote monitoring of UPS as a managed device via network management console applications. Communications ports support messaging of detailed UPS operating parameters and line power status. Includes PowerAlert UPS monitoring and unattended shutdown software with management support for an unlimited number of network UPS systems. Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter. Emergency Power Off (EPO) interface offers option for instantaneous power-off of UPS and connected equipment in the case of fire or emergency. Multi-function audible alarms and set of 5 front panel LEDs offer at-a-glance notification of UPS and line power status. Network-grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges and line noise. Attractive all-black color scheme. Two year warranty with $250,000 connected equipment insurance (USA & Canada only).
Specifications
Power
Output power capacity 1000 VA
Output power 700 W
Input operation voltage (min) 83 V
Input operation voltage (max) 147 V
Output operation voltage (min) 120 V
Output operation voltage (max) 120 V
Surge energy rating 480 J
Maximum current 15 A
Power factor 0.7
Ports & interfaces
AC outlet types NEMA 5–15R
Cable length 3 m
AC outlets quantity 6 AC outlet(s)
Battery
Battery recharge time 4 h
Typical backup time at half load 17 min
Typical backup time at full load 7 min
Hot-swap battery
Cold start
Design
Form factor Rackmount
Rack capacity 1U
Product colour Black
Performance
UPS topology Line-Interactive
Power protection features Over voltage, Under voltage
LED indicators Y
Audible alarm(s)
Features
Input frequency 60 Hz
Technical details
Output frequency 60 Hz
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -15 - 50 °C
Operating relative humidity (H-H) 0 - 95 %
Storage relative humidity (H-H) 5 - 95 %
Certificates
Certification UL 1778: 2014 R8.15 (5TH EDITION); CAN/CSA-C22.2 NO. 107.3-14
Packaging content
Rack mount kit
Manual
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for SM1000RM1UTAA by Tripp Lite you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
